Products in Electrical & Electronics: Prepreg

AtenPly GPE35 are thin sheets of continuous reinforcement fibers impregnated with thermoplastic resin. It is made direct from the fiber roving and thermoplastic melt using proprietary technology developed by Jonam Composites Ltd. This cost-effective efficient process produces light weight, high-strength ,well impregnated, smooth tape with unidirectional fiber reinforcement.

I-Tera MT40 is suitable for many of today’s high speed digital and RF/microwave printed circuit designs. I-Tera MT40 features a dielectric constant (Dk) that is stable between - 55°C and +125°C up to W-band frequencies. In addition, I-Tera MT40 offers a lower dissipation factor (Df) of 0.0031 making it a cost effective alternative to PTFE and other commercial microwave and high-speed digital laminate materials. I-Tera MT40 laminate materials are currently being offered in both laminate and prepreg form in typical thicknesses and standard panel sizes. This provides a complete materials solution package for high-speed digital multilayer, hybrid, RF/microwave, multilayer and double-sided printed circuit designs. I-Tera MT40 does not require any special through hole treatments commonly needed when processing PTFE-based laminate materials.

Lectromat Glass Cloth and Mats 96-193 is applied in coil consolidation.

APCM SG 4528-016AL-104V is a lightweight, conductive, surfacing film composed of a non-woven metallic aluminum mesh impregnated with a toughened epoxy resin plus an ultra light weight veil for outstanding surfacing capability. It is designed for lightning and shielding protection of aircraft, equipotential ground planes and as a counterpoise for antenna installations.

Isola’s IS410 has a glass transition temperature (Tg) of 180°C and is specially formulated for superior performance through multiple thermal excursions, passing 6X solder tests at 288°C. IS410 is optimized for enhanced drilling performance allowing high aspect ratio holes of ≤10 mils. Its unique resin chemistry provides CAF resistance with the benefit of long-term reliability of boards built with small feature designs.

AtenPly GPP35 are thin sheets of continuous reinforcement fibers impregnated with thermoplastic resin. It is made direct from the fiber roving and thermoplastic melt using proprietary technology developed by Jonam Composites Ltd. This cost-effective efficient process produces light weight, high-strength ,well impregnated, smooth tape with unidirectional fiber reinforcement.

APCM DA 4092 is modified epoxy pre-impregnated system which can cure at 250°F (121°C) for one hour. DA 4090 | DA 4092 can be supplied on any commercially available glass, Kevlar, or graphite fabric. DA 4090 is a one sided pre-impregnated fabric yielding a single sided tack material. DA 4092 is the same system where both sides of the fabric are pre-impregnated yielding a double sided tack material. Both prepreg systems can be used for laminating and honeycomb sandwich construction.

P25N consist of a polyimide resin system suitable for military, commercial or industrial electronic applications requiring superior performance and the utmost in thermal properties. These products utilize a polyimide and thermoplastic blend resin, fully cured without the use of Methylenedianiline (MDA). This results in a polymer with a high Tg without the characteristic difficulties of brittleness and low initial bond strength associated with traditional thermoset polyimides.

APCM DA 4518 E-Glass is a modified epoxy system coated on heavy weight unidirectional E-Glass fibers. This product is designed to build excellent unidirectional strength using a minimum number of plies. DA 4518/E-Glass Uni also features extended room temperature out time and service temperatures to 300°F.

TerraGreen® is engineered for such high-performance applications as power amplifier boards for LTE base stations, internet infrastructure and cloud computing. TerraGreen ® features a Dielectric Constant (Dk) that is stable between -55°C and 125°C, up to 20 GHz. TerraGreen® is a lead-free assembly material and is easy to process. This high-performance material utilizes a short-lamination cycle; the product is easy to drill, does not require plasma desmear, and the prepreg shelf life is similar to FR-4 materials. TerraGreen® is suitable for high-layer count, high-speed digital backplanes and is compatible with Isola’s FR-4 materials for hybrid designs. TerraGreen® meets UL 94 V-0 and is halogen free.

OM15 is for visual applications. It is translucent when cured without any white washes. It is Low Tg , about 110 °C.

APCM DA 409U/G35-150 is a tough, versatile, modified epoxy resin prepreg that cures at 250°F, a standard modulus 150 g/m2 carbon prepreg tape which can also be supplied as a 200g/m2 or a 300 g/m2 prepreg.

Aeroglide® is an epoxy-based composite surfacing film which can be oven or autoclave cured at either 250°F/120°C or 350°F/180°C to eliminate surface porosity for composite parts.

AX-3100 is a toughened low dielectric epoxy fiberglass prepreg.

185HR laminate and prepreg materials are manufactured using Isola’s patented technology, reinforced with electrical grade (E-glass) glass fabric. This system delivers a 340°C decomposition temperature, a lower Z-axis expansion and offers lower loss compared to competitive products in this space. The 185HR system is also laser fluorescing and UV blocking for maximum compatibility with Automated Optical Inspection (AOI) systems, optical positioning systems and phot imageable solder mask imaging.

Natex P-Preg PA11 UD 750 is a powder-coated fabric woven from flax fibers that are pre-impregnated with thermoplastic resins. It comes as NATTEX® P-Preg, Polyamide 11 with 1000 mm Width and pre-preg fabrics uni-directional in natural fibers with flax of 750 g/m2.

CM11 resin is Mid Tg and its prepregs are suitable for hot painting, hot gluing and cataphoresis processes. New resin system not only cures under 3 minutes at 150°C at press under isothermal curing conditions but also hot de-moldable and long out-life of two weeks at ambient temperature. These extreme conditions does not affect the visual Performance of prepreg system with CM11, capable of Class A Surface. Drapability is suitable for press molds and low to medium tack optimized for press curing.

CM14 resin is Mid Tg fast cure press curable prepreg system which is also dicy free formulated against waterspot/whitespot problems. CM14 resin system is especially formulated for cosmetic grade visual carbon look. Drapability is suitable for press molds and low to medium tack optimized for press curing.

Lectromat Glass Cloth and Mats WG-601-1 is applied in coil armor tape.

Resinoid 1371 is a glass reinforced, two-step phenolic molding compound offering good mechanical and electrical properties. This product has been specifically formulated for applications requiring prolonged exposure to elevated temperatures andresistance to thermal shocks.This material comes in pelletized from and is suitable for injection, transfer or compression molding. It can be preformed on automatic equipment.

Resinoid 1505 is a milled glass reinforced, two-step phenolic molding compound offering good mechanical and electrical properties. This product has been specifically formulated for electrical applications where very low post-molded shrinkage is desired. This material comes in granular form and is suitable for injection, transfer or compression molding. It can be preformed on automatic equipment.

APCM DA 4090 is modified epoxy pre-impregnated system which can cure at 250°F (121°C) for one hour. DA 4090 | DA 4092 can be supplied on any commercially available glass, Kevlar, or graphite fabric. DA 4090 is a one sided pre-impregnated fabric yielding a single sided tack material. DA 4092 is the same system where both sides of the fabric are pre-impregnated yielding a double sided tack material. Both prepreg systems can be used for laminating and honeycomb sandwich construction.

AtenPly CPA6-35 are thin sheets of continuous reinforcement fibers impregnated with thermoplastic resin. It is made direct from the fiber roving and thermoplastic melt using proprietary technology developed by Jonam Composites Ltd. This cost-effective efficient process produces light weight, high-strength ,well impregnated, smooth tape with unidirectional fiber reinforcement.

Durcomp TPP: Thermoplastic Prepregs is unidirectional, continuous fiber reinforced thermoplastic prepregs with different fiber and resin options, provides mechanical strength, chemical resistance, esthetic appearance etc. of railway vehicle, automotive, white goods, electronics, sports and hobby industries such as the variety to meet the expectations. We support our business partners with solutions aimed at the end use, as well as the production of semi-finished products in the form of unidirectional tape, woven / laminated sheets.

370HR laminates and prepregs, deigned by Polyclad, are made using a patented high performance 180°C Tg FR-4 multifunctional epoxy resin system that is designed for multilayer Printed Wiring Board (PWB) applications where maximum thermal performance and reliability are required. We manufacture 370HR laminates and prepregs with high quality E-glass glass fabric for superior Conductive Anodic Filament (CAF) resistance. 370HR provides superior thermal performance with low Coefficient of Thermal Expansion (CTE) and the mechanical, chemical and moisture resistance properties that equal or exceed the performance of traditional FR-4 materials. 370HR is used in thousands of PWB designs and has proven to be best in class for thermal reliability, CAF performance, ease of processing and proven performance on sequential lamination designs.

PREGNIT TP-PC is a transparent, dimensionally stable, impact resistant, flame retardant possible according to UL94-VO, printable.

OM13 is a structural resin system. It is translucent when cured.

Lectromat Glass Cloth and Mats WG-204 is applied in permanent magnet bonding.

APCM DA 4517 is an epoxy prepreg designed for a temperature range of -67°F (-55°C) to 350°F (177°C), with a cure of 180°F (82°C) for three hour. Shorter cures times are available at higher temperatures. The system is designed to be post cured if the higher temperature service range is required.

APCM SG 4528-015CU-101V is a lightweight, conductive, surfacing film composed of a non-woven metallic copper mesh impregnated with a toughened epoxy resin plus an ultra lightweight veil for outstanding surfacing capability. It is designed for lightning and shielding protection of aircraft, equipotential ground planes and as a counterpoise for antenna installations.

APCM SG 4528-040CU-103V is a heavy weight, conductive, surfacing film composed of a non-woven metallic copper mesh impregnated with a toughened epoxy resin plus an ultra lightweight veil for outstanding surfacing capability. It is designed for lightning and shielding protection of aircraft, equipotential ground planes and as a counterpoise for antenna installations.

Lectromat Glass Cloth and Mats 95-147 is applied in bearing insulation.

APCM DA 4518 is an epoxy prepreg designed for a temperature range of -67°F (-55°C) to 350°F (177°C), with a cure of 250°F (121°C) for one hour and or a cure of 350º F (177ºC) for 1 hour. This material needs to be post cure or cured to 350ºF to get the 350º properties.

FR408 low dielectric constant (Dk) and low dissipation factor (Df) make it an ideal candidate for broadband circuit designs requiring faster signal speeds or improved signal integrity. FR408 is compatible with most FR-4 processes. This feature allows the use of FR408 without adding complexity to current fabrication techniques.

IS420 laminate and prepreg products are manufactured with a unique high performance multifunctional epoxy resin, reinforced with electrical grade (E-glass) glass fabric. This system provides improved thermal performance and low expansion rates in comparison to traditional FR-4 while retaining FR-4 processability. In addition to this superior thermal performance, the mechanical, chemical and moisture resistance properties all equal or exceed the performance of traditional FR-4 materials. The IS420 system is also laser fluorescing and UV blocking for maximum compatibility with Automated Optical Inspection (AOI) systems, optical positioning systems and photo imageable solder mask imaging.

Lectromat Glass Cloth and Mats DG-610 is applied in shrinkable coil armor tape.
