Aegis® H85NP is a medium viscosity, nylon 6 extrusion grade homopolymer for cast or blown BOPA film. It offers a combination of strength, toughness and thermoforming properties as well as excellent heat, chemical and abrasion resistance.
Ask AdvanSix Questions
Ask the Supplier
Popular AdvanSix Products
View All AdvanSix ProductsKnowde Enhanced TDS
Identification & Functionality
Aegis® H85NP Features & Benefits
Applications & Uses
Material Handling
Aegis® H85NP homopolymer is supplied in sealed containers and drying prior to processing is not required. However, high moisture is the primary cause of processing problems. If drying becomes necessary, a dehumidifying or desiccant dryer operating at 80°C (176°F) is recommended. Drying time is dependent on moisture level.
From flexible packaging for food and consumer products to vacuum bagging for industrial goods, Aegis® packaging grade resins are widely used in a variety of applications, including:
- Processed meats and cheeses
- Coffee, nuts and spices
- Snacks and frozen foods
- Pet foods
- Detergent bags
- Composite fabrications
- Medical devices
- Novelty balloons
Properties
| Value | Units | Test Method / Conditions | |
| 96% SAV | 3.19 | - | - |
| Carbon Dioxide Permeability (at 23°C (73°F)/0% RH) | 72.8 (4.697) | cc/m2 /day (cc/100 in2 /day) | - |
| Density | 1.13 | g/cm3 | ASTM D-1505 |
| Equilibrium Moisture (at 50% RH) | 2.7 | % | - |
| Extractable Content | max. 0.6 | % | - |
| Melt Flow Rate (at 235°C/1.0 kg (455°F/1.0 kg)) | 3.5 | g/10 min | ASTM D-1238 |
| Melting Point | 220 (428) | °C (°F) | ASTM D-3418 |
| Moisture Content | max. 0.08 | % | - |
| Nitrogen Permeability (at 23°C (73°F)/0% RH) | 14.0 (0.903) | cc/m2 /day (cc/100 in2 /day) | - |
| Oxygen Permeability (at 23°C (73°F)/0% RH) | 40.3 (2.600) | cc/m2 /day (cc/100 in2 /day) | - |
| Saturation Moisture Content | 9.5 | % | - |
| Viscosity (FAV) | 85 | - | ASTM D-789 |
| Water Absorption (in 24 hrs) | 1.6 | % | - |
Regulatory & Compliance
AdvanSix has more than 50 years of experience in the development and production of packaging resin that is safe and reliable for consumers and businesses. Aegis® packaging resins are manufactured to meet the stringent standards required of materials involved in the processing, handling and packaging of food. They meet all applicable U.S. Food and Drug Administration (FDA) and European Union (EU) food grade regulations, as outlined in FDA 21 CFR 177.1500 and Regulation (EU) No. 10/2011.
Technical Details & Test Data
Melt Viscosity vs. Temperature
Melt Temperature: 220°C (428°F)
Melt Temperature Range: 232°C (450°F) to 271°C (520°F)
Two key factors affect the melt viscosity (stiffness or fluidity of the melt):
- The molecular weight (Mw) of the resin: Higher Mw resins will have a higher melt viscosity than lower Mw resins.
- Temperature of the melt for any given Mw resin: Higher process temperatures will provide a more fluid melt viscosity than lower process temperatures.
Typical Barrel Profile for Cast Films
Barrel: 230-260°C (446-500°F)
Adapter: 260-266°C (500-510°F)
Die: 260°C (500°F)
Process Melt Temperature: 260-270°C (500-518°F)
Typical Barrel Profile for Tubular (Blown) Films
Barrel: 246-254°C (474-490°F)
Adapter: 260°C (500°F)
Die: 254°C (490°F)
Process Melt Temperature: 254-260°C (490-500°F)
Screw Parameters
Metering Section: 40%
Transition Section: 3 to 4 flights
Feed Section: Balance of screw length
Compression Ratio: 3.5:1 to 4.0:1
L/D Ratio: 24:1
Metering Section Flight Depth
| Screw Diameter | Recommended Depth |
| 1" | 0.055" |
| 1.5" | 0.060" |
| 2" | 0.070" |
| 2.5" | 0.080" |
| 3.5" | 0.100" |
| 4.5" | 0.115" |
| 6" | 0.135" |
