Aegis® H350ZI resin is an unfilled ultra high-viscosity nylon 6 homopolymer with excellent processability and structural properties for profile extrusion. It combines strength, stiffness and toughness with superior heat, chemical and abrasion resistance.

Polymer Name: Polyamide 6 (PA 6)

Processing Methods: Extrusion, Profile Extrusion

Technical Data Sheet

Knowde Enhanced TDS

Identification & Functionality

Polymer Name
Technologies

Features & Benefits

Applications & Uses

Plastics & Elastomers Processing Methods
Processing Guidelines

Material Handling
This product is supplied in sealed containers and drying prior to processing is not required. However, higher moisture is the primary cause of processing problems. If drying becomes necessary, a dehumidifying or desiccant dryer operating at 80°C (176°F) is recommended. Drying time is dependent on moisture level. Further information concerning safe handling procedures can be obtained from the Safety Data Sheet. Alternatively, please contact your AdvanSix representative.

Properties

Color
Mechanical Properties
ValueUnitsTest Method / Conditions
Tensile Modulus (23°C (73°F))2,616 (379,468)MPa (psi)ISO 527-2
Tensile Strength (23°C (73°F))96 (13,926)MPa (psi)ISO 527-2
Elongation at Yield (23°C (73°F))5.63%ISO 527-2
Elongation at Break (at 23°C (73°F))46.3%ISO 527-2
Notched Izod impact (at 23°C (73°F))1.294ft-lbf/inASTM D-256
Typical Properties
ValueUnitsTest Method / Conditions
Viscosity, FAV400ASTM D-789
RV (at 96% Sulfuric Acid, RV calculated from FAV)5.3ASTM D-789
Extractable Contentmax. 0.9%SOP-702-307
Specific Gravity (at 23°C (73°F))1.13ASTM D-792
Melt Flow Rate (at 280°C (536°F), 2.16Kg)2.6g/10 minInternal SOP
Moisture Contentmax. 0.12%ASTM D-6869
Thermal Properties
ValueUnitsTest Method / Conditions
Melting Point220°C (428°F)°C (°F)ASTM D-3418
Other Properties
ValueUnitsTest Method / Conditions
Pellet Size0.834g/100 pelletsInternal SOP

Technical Details & Test Data

Extrusion Guidelines

Melt Viscosity vs. Temperature
Polymer Melt Temperature: 220°C (428°F)
Two main factors affect the melt viscosity (stiffness or fluidity of the melt):
1. The molecular weight (MW) of the resin: Higher MW resins will have a higher melt viscosity than lower MW resins.
2. Temperature of the melt for any given MW resin: Higher process temperatures will provide a more fluid melt viscosity than lower process temperatures.

Typical Profile
Extruder Barrel Temperature settings 240-290 °C (464-554 °F)

Note: The values in this data sheet are for natural color resins only. Colorants or other additives may alter some or all of these properties. The data listed here fall within the normal range of product properties, but should not be used to establish specification limits nor used alone as the basis of design.
