Aegis® PIR-H100QP

Sold by AdvanSix
Polymer Name: Polyamide 6 (PA 6)
Additives Included: Lubricant (Unspecified)
Labeling Claims: Recycled, Contains PIR Resin, Food Contact Acceptable, Sustainable
Processing Methods: Extrusion, Cast Film Extrusion, Blown Film Extrusion, Film Extrusion, Thermoforming
Density: 1130.0 kg/m³
Start Order
Secure
Order Quantity
Price
Available upon quote
Minimum Order Quantity
Quote required
Lead Time
Quote required
Available Incoterms
Quote required
Regional Availability
Quote required

Ask AdvanSix Questions

User Avatar
User Avatar
User Avatar

Ask the Supplier

User Avatar
User Avatar
User Avatar
TypeDocument Name
Brochure
Aegis® Resins and Capran® BOPA Films Brochure
Aegis® Resins and Capran® BOPA Films Brochure
Brochure
Other
Aegis® PIR Environmental Claims Validation - SCS Certificate
Aegis® PIR Environmental Claims Validation - SCS Certificate
Other
Technical Data Sheet
Aegis® PIR-H100QP Technical Data Sheet
Aegis® PIR-H100QP Technical Data Sheet
Technical Data Sheet

Knowde Enhanced TDS

Expand All

+

Identification & Functionality

Aegis® PIR-H100QP Features & Benefits

Applications & Uses

Application

Aegis® PIR-H100QP is a lubricated, medium viscosity, nylon 6 extrusion grade homopolymer for cast or blown film

Properties

Physical Form
Thermal Properties
ValueUnitsTest Method / Conditions
Melting Point220 (428)ºC (ºF)D-3418
Typical Properties
ValueUnitsTest Method / Conditions
96% SAV3.37--
Density1.13g/cm³ASTM D-1505
Melt Flow Rate (at 235°C/1.0 kg or 455°F/1.0 kg)2.6g/10 minD-1238
Viscosity (FAV)100-D-789
Gas Barrier Properties
ValueUnitsTest Method / Conditions
Carbon Dioxide Permeability (at 23°C (73°F), 0% RH)72.8 (4.697)cc/m²/day (cc/100 in2/day)-
Nitrogen Permeability (at 73°F (23°C), 0% RH)14.0 (0.903)cc/m²/day (cc/100 in2/day)-
Oxygen Permeability (at 73°F (23°C), 0% RH)40.3 (2.600)cc/m²/day (cc/100 in2/day)-
Moisture Properties
ValueUnitsTest Method / Conditions
Equilibrium Moisture (at 50% RH)2.7%-
Extractable Contentmax. 0.8%-
Moisture Contentmax. 0.08%-
Saturation Moisture Content9.5%-
Water Absorption in 24 hrs1.6%-
Note

Aegis® PIR-H100QP conforms to FDA requirements of 21 CFR 177.1500 as well as EU Directive 2011/10/EC. Aegis® PIR-H100QP homopolymer possesses the combination of strength, toughness and thermoforming properties associated with nylon 6 as well as excellent heat, chemical and abrasion resistance.

Regulatory & Compliance

Technical Details & Test Data

Extrusion Guidelines

Melt Viscosity vs. Temperature

Melt Temperature: 220°C (428°F)
Melt Temperature Range: 232°C (450°F) to 271°C (520°F).
Two key factors affect the melt viscosity (stiffness or fluidity of the melt) :
1. The molecular weight (Mw) of the resin: Higher Mw resins will have a higher melt viscosity than lower Mw resins.
2. Temperature of the melt for any given Mw resin: Higher process temperatures will provide a more fluid melt viscosity
than lower process temperatures.



Typical Barrel Profile for Cast Films

Barrel: 230-260°C (446-500°F)
Adapter: 260-266°C (500-510°F)
Die: 260°C (500°F)
Process Melt Temperature: 260-270°C (500-518°F)



Typical Barrel Profile for Tubular (Blown) Films

Barrel: 246-254°C (474-490°F)
Adapter: 260°C (500°F)
Die: 254°C (490°F)
Process Melt Temperature: 254-260°C (490-500°F)



Screw Parameters

Metering Section: 40%
Transition Section: 3 to 4 flights
Feed Section: Balance of screw length
Compression Ratio: 3.5:1 to 4.0:1
L/D Ratio: 24:1



Metering Section Flight Depth

Screw Diameter Recommended Depth
1" 0.055"
1.5" 0.060"
2" 0.070"
2.5" 0.080"
3.5" 0.100"
4.5" 0.115"
6" 0.135"



Storage & Handling

Processing Guidelines

Material Handling

Aegis® PIR-H100QP is supplied in sealed containers and drying prior to processing is not required. However, higher moisture is the primary cause of processing issues. If drying becomes necessary, a dehumidifying or desiccant dryer operating at 80°C (176°F) is recommended. Drying time is dependent on moisture level. More information about safe handling procedures can be obtained by requesting the Safety Data Sheet.
