Delrin 500CL NC010 - DuPont - POM Homopolymer

Polymer Name: Polyacetal Homopolymer (POM)

Processing Methods: Injection Molding

Additives Included: Mold Release Agent, Lubricant (Unspecified)

Flexural Modulus: 2900.0 MPa

Start Order

Secure

Order Quantity

Price

Available upon quote

Minimum Order Quantity

Quote required

Lead Time

Quote required

Available Incoterms

Quote required

Regional Availability

View

Delrin® 111PA NC010 Polyacetals Industrial & Transport Packaging, Sports & Recreation, Other Consumer Goods Applications, Housewares, Exterior & Body, Housings & Enclosures, Connectors, Consumer Electronics, Stationery, Art & Office Supplies, Appliances & Electronics, Interior, Fuel Systems, Chassis & Brake

Delrin® SC698 NC010 Polyacetals Wound Care, Tubing & Fluids Handling, Surgical Instruments & Trays, Implants & Prosthetics, Sports & Recreation, Other Consumer Goods Applications, Other Automotive Applications, Appliances & Electronics, Other Devices & Assemblies, Other Industrial Applications

Delrin® FG511DP NC010 Polyacetals Food & Beverage Packaging, Industrial & Transport Packaging, Food Films & Packaging, Sports & Recreation, Other Consumer Goods Applications, Housewares, Exterior & Body, Housings & Enclosures, Connectors, Consumer Electronics, Stationery, Art & Office Supplies, Appliances & Electronics, Interior, Fuel Systems, Chassis & Brake

Documents

Knowde Enhanced TDS

Expand All

Identification & Functionality

Additives Included

Lubricant (Unspecified),

Mold Release Agent

Polymer Name

Polyacetal Homopolymer (POM)

Plastics & Elastomers Functions

Resin

Technologies

Plastics

Product Families

Plastics — Engineering & Specialty Polymers

Polyacetals

Delrin® 500CL NC010 Features & Benefits

Materials Features

Applications & Uses

Markets

Automotive & Transportation,

Electrical & Electronics

Applications

Automotive & Transportation — Automotive

Other Automotive Applications,

Powertrain & UTH

Electrical & Electronics — Devices & Assemblies

Automotive Electronics,

Other Devices & Assemblies

Plastics & Elastomers End Uses

Automotive Applications,

Gears

Plastics & Elastomers Processing Methods

Injection Molding

Properties

Mechanical Properties


	Value	Units	Test Method / Conditions
Tensile Modulus	3100	MPa	ISO 527-1/-2
Yield Stress	70	MPa	ISO 527-1/-2
Yield Strain	15	%	ISO 527-1/-2
Flexural Modulus	2900	MPa	ISO 178
Nominal Strain (at Break)	25	%	ISO 527-1/-2
Poisson's Ratio	0.37	-	-
Tensile Creep Modulus (1000h)	1600	MPa	ISO 899-1
Charpy Impact Strength (at 23°C)	350	kJ/m²	ISO 179/1eU
Charpy Impact Strength (at -30°C)	290	kJ/m²	ISO 179/1eU
Notched Charpy Impact Strength (at 23°C)	8	kJ/m²	ISO 179/1eA
Notched Charpy Impact Strength (at -30°C)	7	kJ/m²	ISO 179/1eA
Notched Izod Impact Strength (at 23°C)	9	kJ/m²	ISO 180/1A
Notched Izod Impact Strength (at -40°C)	9	kJ/m²	ISO 180/1A
Hardness (Rockwell Scale M)	92	-	ISO 2039-2
Hardness (Rockwell Scale R)	120	-	ISO 2039-2

Typical Properties


	Value	Units	Test Method / Conditions
Resin Identification	POM	-	ISO 1043

Thermal Properties


	Value	Units	Test Method / Conditions
Melt Temperature (at 10°C/min)	178	°C	ISO 11357-1/-3
Temperature of Deflection Under Load (1.8 Mpa)	90	°C	ISO 75-1/-2
Temperature of Deflection Under Load (0.45 Mpa)	158	°C	ISO 75-1/-2
Vicat Softening Temperature (at 50°C/H 50N)	160	°C	ISO 306
Coefficient of Linear Thermal Expansion (Parallel)	110	E-6/K	ISO 11359-1/-2
Coefficient of Linear Thermal Expansion (Normal)	110	E-6/K	ISO 11359-1/-2
Relative Thermal Index (Electrical, 0.75mm)	50	°C	UL 746B
Relative Thermal Index (Electrical, 1.5mm)	100	°C	UL 746B
Relative Thermal Index (Electrical, 3mm)	100	°C	UL 746B
Relative Thermal Index (Impact, 0.75mm)	50	°C	UL 746B
Relative Thermal Index (Impact, 1.5mm)	80	°C	UL 746B
Relative Thermal Index (Impact, 3mm)	80	°C	UL 746B
Relative Thermal Index (Strength, 0.75mm)	50	°C	UL 746B
Relative Thermal Index (Strength, 1.5mm)	85	°C	UL 746B
Relative Thermal Index (Strength, 3mm)	85	°C	UL 746B
TGA curve	available	-	ISO 11359-1/-2

Electrical Properties


	Value	Units	Test Method / Conditions
Surface Resistivity	min. 1E15	Ohm	IEC 62631-3-2
Relative Permittivity (at 100Hz)	4.2	-	IEC 62631-2-1
Relative Permittivity (at 1MHz)	4.1	-	IEC 62631-2-1
Dissipation Factor (at 1 MHz)	60	E-4	IEC 62631-2-1
Comparative Tracking Index	600	-	IEC 60112

Flammability


	Value	Units	Test Method / Conditions
FMVSS Class	B	-	ISO 3795 (FMVSS 302)
Burning Behavior (at 1.5mm Nominal Thickness)	UL94 HB	class	IEC 60695-11-10
Burning Behavior (at 0.75mm Thickness)	UL94 HB	class	IEC 60695-11-10
Glow Wire Flammability Index (at 3mm)	550	°C	IEC 60695-2-12
Burning Rate (at 1mm Thickness)	28	mm/min	ISO 3795 (FMVSS 302)

Other Properties


	Value	Units	Test Method / Conditions
Humidity Absorption (at 2mm)	0.25	%	Sim. to ISO 62
Water Absorption (at 2mm)	1	%	Sim. to ISO 62
Density	1410	kg/m³	ISO 1183

Processing Information (Injection Molding)


	Value	Units	Test Method / Conditions
Drying Recommended	yes	-	-
Drying Temperature	80	°C	-
Drying Time (Dehumidified Dryer)	2 - 4	h	-
Processing Moisture Content	max. 0.2	%	-
Hold Pressure Range	80 - 100	MPa	-
Hold Pressure Time	8	s/mm	-
Annealing Temperature	160	°C	-
Melt Temperature (Optimum)	215	°C	-
Melt Temperature (Minimum)	210	°C	-
Melt Temperature (Maximum)	220	°C	-
Maximum Screw Tangential Speed	0.3	m/s	-
Mold Temperature (Optimum)	90	°C	-
Mold Temperature (Minimum)	80	°C	-
Mold Temperature (Maximum)	100	°C	-
Annealing Time (Optional)	30	min/mm	-

Rheological Properties


	Value	Units	Test Method / Conditions
Melt Volume-Flow Rate (at 190°C, 2.16 kg)	12	cm³/10min	ISO 1133
Melt Mass Flow Rate (at 190°C, 2.16 kg)	15	g/10min	ISO 1133
Mold Shrinkage (Parallel)	1.9	%	ISO 294-4, 2577
Mold Shrinkage (Normal)	1.8	%	ISO 294-4, 2577

Chemical Resistance

Chemical Type	Chemical Name	Resistance
Acids	Acetic Acid (5% by mass) (23°C)	Probably Resistant
Acids	Chromic Acid solution (40% by mass) (23°C)	Not Recommended
Acids	Citric Acid solution (10% by mass) (23°C)	Not Recommended
Acids	Hydrochloric Acid (36% by mass) (23°C)	Not Recommended
Acids	Lactic Acid (10% by mass) (23°C)	Not Recommended
Acids	Nitric Acid (40% by mass) (23°C)	Not Recommended
Acids	Sulfuric Acid (38% by mass) (23°C)	Not Recommended
Acids	Sulfuric Acid (5% by mass) (23°C)	Not Recommended
Alcohols	Ethanol (23°C)	Probably Resistant
Alcohols	Isopropyl alcohol (23°C)	Probably Resistant
Alcohols	Methanol (23°C)	Probably Resistant
Bases	Ammonium Hydroxide solution (10% by mass) (23°C)	Not Recommended
Bases	Sodium Hydroxide solution (1% by mass) (23°C)	Not Recommended
Bases	Sodium Hydroxide solution (35% by mass) (23°C)	Not Recommended
Ethers	Diethyl ether (23°C)	Probably Resistant
Hydrocarbons	iso-Octane (23°C)	Probably Resistant
Hydrocarbons	n-Hexane (23°C)	Probably Resistant
Hydrocarbons	Toluene (23°C)	Probably Resistant
Ketones	Acetone (23°C)	Probably Resistant
Mineral oils	Insulating Oil (23°C)	Probably Resistant
Mineral oils	SAE 10W40 multigrade motor oil (130°C)	Not Recommended
Mineral oils	SAE 10W40 multigrade motor oil (23°C)	Probably Resistant
Mineral oils	SAE 80/90 hypoid-gear oil (130°C)	Not Recommended
Other	1% nonylphenoxy-polyethyleneoxy ethanol in water (23°C)	Probably Resistant
Other	50% Oleic acid + 50% Olive Oil (23°C)	Probably Resistant
Other	DOT No. 4 Brake fluid (130°C)	Not Recommended
Other	Ethyl Acetate (23°C)	Probably Resistant
Other	Ethylene Glycol (50% by mass) in water (108°C)	Not Recommended
Other	Hydrogen peroxide (23°C)	Not Recommended
Other	Phenol solution (5% by mass) (23°C)	Not Recommended
Other	Water (23°C)	Probably Resistant
Other	Water (90°C)	Not Recommended
Salt solutions	Sodium Carbonate solution (2% by mass) (23°C)	Not Recommended
Salt solutions	Sodium Carbonate solution (20% by mass) (23°C)	Not Recommended
Salt solutions	Sodium Chloride solution (10% by mass) (23°C)	Probably Resistant
Salt solutions	Sodium Hypochlorite solution (10% by mass) (23°C)	Not Recommended
Salt solutions	Zinc Chloride solution (50% by mass) (23°C)	Not Recommended
Standard Fuels	Diesel fuel (pref. ISO 1817 Liquid F) (>90°C)	Not Recommended
Standard Fuels	Diesel fuel (pref. ISO 1817 Liquid F) (23°C)	Probably Resistant
Standard Fuels	Diesel fuel (pref. ISO 1817 Liquid F) (90°C)	Not Recommended
Standard Fuels	ISO 1817 Liquid 1 - E5 (60°C)	Probably Resistant
Standard Fuels	ISO 1817 Liquid 2 - M15E4 (60°C)	Probably Resistant
Standard Fuels	ISO 1817 Liquid 3 - M3E7 (60°C)	Probably Resistant
Standard Fuels	ISO 1817 Liquid 4 - M15 (60°C)	Probably Resistant
Standard Fuels	Standard fuel with alcohol (pref. ISO 1817 Liquid 4) (23°C)	Probably Resistant
Standard Fuels	Standard fuel without alcohol (pref. ISO 1817 Liquid C) (23°C)	Probably Resistant
