Ottopol 25-30 is the ammonia-cut version of Ottopol 25-50E. This solution polymer has good adhesion to non-porous surfaces. Belonging to the Ottopol 25 Series, it is specifically designed for use as a grinding and letdown vehicle for water-based rotogravure and flexographic inks. It provides high gloss and excellent press stability. Ink and coating makers will benefit from the versatility of this series as a sole binder or component of high-gloss inks and overlay varnishes. These polymers are derived from the same monomer composition, and the dry resin is identical throughout the series.

Functions: Binder & Resin, Grinding Aid

Chemical Family: Acrylics & Acrylates

Compatible Polymers & Resins: Cellulose & Cellulosics, Polyesters, Polystyrenes (PS), Polyvinyl Chloride (PVC)

Knowde Enhanced TDS

Identification & Functionality

Chemical Family
CASE Ingredients Functions
Technologies

Features & Benefits

Product Highlights

Superior Printing Qualities

  • Ottopol 25 Series’ unique characteristics impart excellent flow and leveling to inks and coatings, making gravure print quality possible that could only be attained with solvent systems in the past. The viscosity curve of this resin is relatively flat and shows a very low degree of thixotropy. The result is superior printing quality.



Good Pigment Wetting

  • High industry standards are met when Ottopol 25 Series is used as a dispersion stabilizer, or purely for wetting purposes. Optimum color development is achieved with a large variety of pigments.



Excellent Gloss

  • The rheological properties of Ottopol 25 solutions contribute to high gloss, while the use of maximum amounts of alcohol will increase the gloss of this resin.



Excellent Adhesion to Substrates

  • On PVC, Polyester, Polystyrene, and Coated Cellophane, this series of polymers provide excellent adhesion.

Applications & Uses

Coating Type
Formulations

Pigment Concentrates

Materials Parts by Weight  -1 Parts by Weight -2
Ottopol 25-30 29 19
Water   10
Organic Presscake 50% 70
Inorganic Pigment   70
Defoamer 1 1
Total 100 100

Procedure: Same as above (Flexographic Inks).



Flexographic & Gravure Inks

Materials Parts by Weight  -1 Parts by Weight -2
Ottopol 25-30 43 40
Isopropyl Alcohol 14 10
Ottopol Wax 35 5 5
Aerosol OT 75 1 1
Pigment Concentrate 20 36
Water 17 9
Total 100 100

Procedure: Same as above (Flexographic & Gravure Inks)

Properties

Physical Form
Appearance
Clear viscous
Specifications
ValueUnitsTest Method / Conditions
Freeze Thaw Stability5 Cycles--
pH8.0 - 9.0--
Solids Content29.0 - 31.0%-
Specific Gravity1.075--
Glass Transition Temperature43°C-
Viscosity 2000 - 4000 cps-
Weight / Gallon8.96lbs-

Regulatory & Compliance

Chemical Inventories
