Ottopol 25-30

Ottopol 25-30 is the ammonia-cut version of Ottopol 25-50E. This solution polymer has good adhesion to non-porous surfaces. Belonging to the Ottopol 25 Series, it is specifically designed for use as a grinding and letdown vehicle for water-based rotogravure and flexographic inks. It provides high gloss and excellent press stability. Ink and coating makers will benefit from the versatility of this series as a sole binder or component of high-gloss inks and overlay varnishes. These polymers are derived from the same monomer composition, and the dry resin is identical throughout the series.

Function: Binder, Grinding Aid

Chemical Family: Acrylics & Acrylates

Compatible Polymers & Resins: Polystyrenes (PS), Polyesters, Polyvinyl Chloride (PVC), Cellulose & Cellulosics

Start Order

Secure

Order Quantity

Price

Available upon quote

Minimum Order Quantity

Quote required

Lead Time

Quote required

Available Incoterms

Quote required

Regional Availability

Quote required

Ask Gellner Questions

Ask the Supplier

Ottopol K-672 Acrylics

Ottopol M-49 Acrylics

Ottopol 510-28 Acrylics

Documents Experts

TypeDocument Name

Technical Data Sheet

Ottopol 25-30 Technical Data Sheet

Technical Data Sheet

Safety Data Sheet

Ottopol 25-30 Safety Data Sheet

Safety Data Sheet

See All Documents

Knowde Enhanced TDS

Expand All

Identification & Functionality

Chemical Family

Acrylics & Acrylates

CASE Ingredients Functions

Binder & Resin,

Grinding Aid

Technologies

CASE Ingredients

Product Families

CASE Ingredients — Additives

Functional Additives

CASE Ingredients — Resins & Binders

Acrylics

Ottopol 25-30 Features & Benefits

CASE Ingredients Features

Excellent Adhesion,

Excellent Flow,

Good Leveling,

Good Pigment Wetting,

Good Printability,

High Gloss,

Multi-Substrate Adhesion

Product Highlights

Superior Printing Qualities

Ottopol 25 Series’ unique characteristics impart excellent flow and leveling to inks and coatings, making gravure print quality possible that could only be attained with solvent systems in the past. The viscosity curve of this resin is relatively flat and shows a very low degree of thixotropy. The result is superior printing quality.

Good Pigment Wetting

High industry standards are met when Ottopol 25 Series is used as a dispersion stabilizer, or purely for wetting purposes. Optimum color development is achieved with a large variety of pigments.

Excellent Gloss

The rheological properties of Ottopol 25 solutions contribute to high gloss, while the use of maximum amounts of alcohol will increase the gloss of this resin.

Excellent Adhesion to Substrates

On PVC, Polyester, Polystyrene, and Coated Cellophane, this series of polymers provide excellent adhesion.

Applications & Uses

Markets

Paints & Coatings,

Printing & Packaging

Applications

Printing & Packaging — Packaging Coatings

Overprint Varnishes

Paints & Coatings — Packaging Coatings

Overprint Varnishes

Printing & Packaging — Printing & Inks

Flexography,

Gravure Printing

Compatible Polymers & Resins

Cellulose & Cellulosics,

Polyesters,

Polystyrenes (PS),

Polyvinyl Chloride (PVC)

Coating Type

Ink & Toner Type

Formulations

Pigment Concentrates

Materials	Parts by Weight -1	Parts by Weight -2
Ottopol 25-30	29	19
Water		10
Organic Presscake 50%	70
Inorganic Pigment		70
Defoamer	1	1
Total	100	100

Procedure: Same as above (Flexographic Inks).

Flexographic & Gravure Inks

Materials	Parts by Weight -1	Parts by Weight -2
Ottopol 25-30	43	40
Isopropyl Alcohol	14	10
Ottopol Wax 35	5	5
Aerosol OT 75	1	1
Pigment Concentrate	20	36
Water	17	9
Total	100	100

Procedure: Same as above (Flexographic & Gravure Inks)

Properties

Physical Form

Emulsion,

Liquid

Appearance

Clear viscous

Specifications


	Value	Units	Test Method / Conditions
Freeze Thaw Stability	5 Cycles	-	-
pH	8.0 - 9.0	-	-
Solids Content	29.0 - 31.0	%	-
Specific Gravity	1.075	-	-
Glass Transition Temperature	43	°C	-
Viscosity	2000 - 4000	cps	-
Weight / Gallon	8.96	lbs	-
