Ottopol K-362 is a solution polymer for alkali resistance and adhesion to non-porous substrates. This product is suitable for use as a grinding vehicle for organic and inorganic pigments. Additionally, pigment concentrates can be let down with these resins to produce printing inks and coatings.

Functions: Binder & Resin, Grinding Aid

Chemical Family: Acrylics & Acrylates

Compatible Substrates & Surfaces: Metal, Paper, Plastics, Textiles

Knowde Enhanced TDS

Identification & Functionality

Carrier
Chemical Family
CASE Ingredients Functions
Technologies

Features & Benefits

Product Highlights

INSOLUBLE IN ALKALI

  • Ottopol K-21-30 and K-362 are Low molecular weight cationic acrylic resin solutions. It is suitable for use as a grinding vehicle for organic and inorganic pigments. Pigment concentrates can be let down with these resins to produce printing inks and coatings. A clear coating or overlay varnish may be formulated as well.



ALKALI RESISTANCE

  • The dry resin is impermeable to alkali without the use of crosslinking agents. Inks and overlay varnishes for soap boxes and household paper towels will not be affected by the high pH of the detergent cleaner used with the paper towels.



ADHESION TO SUBSTRATES

  • Their positive charge allows inks and coatings to have exceptionally good adhesion to plastic films: Mylar, PVC, and polystyrene. Adhesion to foil and other metallic surfaces is excellent.



DYE INKS

  • Both products are effective solubilizers for oil soluble dyes and are compatible with basic dyes.
  • Ottopol K-362 is a resin solution in water.



Applications & Uses

Compatible Substrates & Surfaces
Coating Type
Formulations

PIGMENT CONCENTRATES

Materials Parts by Weight -1 Parts by Weight -2 Parts by Weight -3
Ottopol K-362 40 40 31
Water 30 30 19
Barium Lithol Red 20-4210* 30
Phthalocyanin   30
Titanium Dioxide     50
Total 100 100 100

Procedure: Place all components into a mill and grind until the appropriate gage reading is attained.



PIGMENT CONCENTRATES USING PRESSCAKES

Materials Parts by Weight -1 Parts by Weight -2
Ottopol K-362 40 30
Presscake Organic 50% 60
Presscake Inorganic 50%   70
Total 100 100

Procedure: Place all components into a container equipped with a high speed stirrer. Stir until desired gage reading is attained.



FLEXOGRAPHIC INKS

Materials Parts by Weight -1 Parts by Weight -2 Parts by Weight -3
Pigment Concentrate No. 1 40
Pigment Concentrate No. 2   40
Pigment Concentrate No. 3     50
Ottopol K-362 59 59 49
Perenol S-5 1 1 1
Total 100 100 100

Procedure: Place all components into a mixing tank and stir until homogeneous.

The above ink will have a viscosity of 500-800 cps and can be diluted with water at press site to desired viscosity. Pigment concentrates derived of presscakes can be used in the above formulations by following the respective numbers.

Properties

Physical Form
Appearance
Slightly hazy solution
Specifications
ValueUnitsTest Method / Conditions
Freeze Thaw Stability5 Cycles--
Glass Transition Temperature43°C-
pH5.0 - 6.0--
Solids Content29.0 - 31.0%-
Specific Gravity1.05--
Viscosity 200 - 400 cps-
Weight / Gallon8.75lbs-

Regulatory & Compliance

Chemical Inventories
