Knowde Enhanced TDS
Identification & Functionality
- Carrier
- Chemical Family
- CASE Ingredients Functions
- Technologies
- Product Families
Features & Benefits
- CASE Ingredients Features
Applications & Uses
- Compatible Polymers & Resins
- Formulations
Starting Point Formulation “A” Two Component system
Part A
Ottopol KX-99 78.8 Water 9.1 *BYK 3450 0.1 In 2 hours ambient cure, the film will have over 100 double rubs acetone resistance
Part B
**AP Silane 51Epoxy Silane 7.0 ***Bayhydur 305 4.7 Mix components in the order listed for 30 minutes. Resulting viscosity will be 25-30 seconds #2 Zahn Cup. The Masurf FS-2800 is a fluorocarbon wetting agent and is quite effective with this system.
*BYK (203) 265-2086
** Advanced Polymer (201) 933-0600
*** Bayer Material Science (412) 777-2000
Polyisocyanate Free Formula
Ottopol KX-99 is a Hydroxyl Functional Cationic Acrylic Solution Polymer. This polymer will crosslink at room temperature with Dow Corning Epoxy Silane Z-6040. We recommend a maximum of 20% Silane based on resin solids. The ambient dried film will have excellent resistance to solvents, such as, MEK, Acetone and IPA. Detergents and cleaners will not remove this film. Water resistance is excellent. The dried film will also resist staining.
Starting Point Formulation “B” Two Component system
Part A
Ottopol KX-99 72.3 Water 20.3 *BYK 3450 0.1 Solvent Resistant Coating, Resists MEK, Acetone & Isopropyl Alcohol, Ambient cure in 72 hours
Part B
**AP Silane 51 Epoxy Silane 7.0 Mix components in the order listed for 30 minutes. Resulting viscosity will be 15-20 seconds #2 Zahn Cup. The Masurf FS-2800 is a fluorocarbon wetting agent and is quite effective with this system. The pot life will be 72 hours
*BYK Chemie (203) 265-2086
** Advanced Polymer (201) 933-0600
Starting Point Formula “C” Two Component system
Accelerated Cure Rate Coating for Chemical Resistance in 14 Hours (Ambient Cure) Polyisocyanate Free
Part A
Ottopol KX-99 72.3 Water 8.3 *Bindzil CC401 Silica 37% Active 14.7 **BYK 3450 0.1 Part B
*** AP Silane 51 Epoxy Silane 4.3 Mix components in the order listed for 30 minutes. Resulting viscosity will be 25-30 seconds #2 Zahn Cup. The Masurf FS-2800 is a fluorocarbon wetting agent and is quite effective with this system.
*Eka Chemicals (770) 578-0858
**BYK Chemie (203) 265-2086
*** Advanced Polymer (201) 933-0600
Properties
- Appearance
- Clear solution
- Specifications
| Value | Units | Test Method / Conditions | |
| Flash Point | Same as water | — | — |
| Freeze Thaw Stability | 5 Cycles | — | — |
| Glass Transition Temperature | 32 | °C | — |
| pH | 5.0 - 6.0 | — | — |
| Solids Content | 29.0 - 31.0 | % | — |
| Specific Gravity | 1.0442 | — | — |
| Viscosity | 300 - 800 | cps | — |
| Weight / Gallon | 8.71 | lbs | — |
Regulatory & Compliance
- Chemical Inventories
Technical Details & Test Data
- Performance and Attributes of Formulated Product
For concrete coatings the cured film resists the following:
Gasoline, Motor Oil, Anti-freeze, Brake Fluid and Alkaline Cleaners commonly used for concrete and Hot Tire Mark.
Heat Seal Test: 230 Celsius (446 F) @ 45 psi for one second face to face: Pass
The crosslinked and cured film exhibits high heat resistance while remaining flexible and will not crack when applied to thin film surfaces such as Mylar. Folding the Mylar in half will not crack the film or have any loss of adhesion.
Hard Tough Mar Resistance Film:
- Pencil Hardness: Surpasses 6H
- Konig (Pendulum): 163 seconds
- Konig (Pendulum) addition of Silica to coating: 173 seconds
Cure Rate to Achieve Chemical Resistance at Ambient Temperatures
- Starting Point Formula “A”: 2 Hours
- Starting point formula “B”: 72 Hours
- Starting point formula “C” : 14 Hours
Pot Life of Wet Sample
- Starting Point Formula “A”: 8 Hours
- Starting point formula “B”: 72 Hours
- Starting point formula “C”: 14 Hours
Chemical Resistance (Ambient Cure)
- 150 Double Rubs MEK: Pass
- 150 Double Rubs Acetone: Pass
- 150 Double Rubs Isopropyl Alcohol: Pass
Differences Between the Polyisocyanate Free, the Polyisocyanate containing Formula
The biggest difference is the cure cycle. Formula “A” will have solvent resistance in 2 hours, Formula “B” takes 72 hours and Formula “C” takes 14 hours. Formula “B” and “C” would be the safest and friendliest because the epoxy silane has FDA 177.1390 approval for direct contact with food as a component of a coating that sees over 350 Fahrenheit and contains no polyisocyanate. Our acrylic polymer KX-99 has no hazards, with the exception of a small percentage of Isopropyl Alcohol and Acetic Acid.
