Crystic® Pipe Relining Resin 4044TV01

1 of 176 products in this brand
Crystic® Pipe Relining Resin 4044TV01 is a thixotropic, non-accelerated ISO/NPG unsaturated polyester resin with a low exotherm. It is specially designed for the pipe-relining market, with good chemical resistance and mechanical properties. This resin is suitable for polyester felt or glass fiber reinforcement.

Polymer Name: Thermoset Polyester

Functions: Resins, Binders & Matrix Materials, Surface Finish

Chemical Family: Isophthalics, Unsaturated Polyester (UPE)

Technical Data Sheet

Knowde Enhanced TDS

Identification & Functionality

Features & Benefits

Features and Benefits
  • High HDT
  • High molecular weight
  • High elongation
  • Long term experience
  • Excellent mechanical properties
  • Excellent resistance to water ingress
  • Excellent impact resistance
  • Safety in use
Chemical resistance

CRYSTIC 4044T V01 chemical resistance can be checked in the “Safe Chemical Containment” brochure from Scott Bader, or advice can be obtained by contacting our technical department.

Applications & Uses

Markets
Composites End Use
Recommended Applications

CRYSTIC 4044T V01 has been specially developed for the production of liners to be used in the pipe relining industry. Fully cured laminates offer high chemical resistance and mechanical properties, together with excellent long term property retention.

Formulation Guidelines

The following formulation is recommended for hot curing (80 – 85°C)

  • CRYSTIC 4044T V01 : 100 parts
  • Perkadox 16 : 0.5 - 1 %
  • Trigonox C : 1 – 1.5 %

Perkadox 16 and Trigonox C are products from AKZO.

Properties

Typical Liquid Resin Properties
ValueUnitsTest Method / Conditions
Viscosity (at 25°C, Brookfield RVT, Sp n°4, 5 rpm)45 - 50dPa.s
Thixotropic Index (5/50 rpm)2.5 - 2.9
Specific Gravity (at 25°C)1.1
Acid Index12 - 16mg KOH/g
Volatile Content37 - 41%
Stability (in dark at 20°C)6Months
Time to Peak (Reactivity at 80°C with 0.8% Perkadox 16 + 1% Trigonox C)7 - 8Minutes
Peak Temperature (Reactivity at 80°C with 0.8% Perkadox 16 + 1% Trigonox C)250°C
Stability (at 20°C, with 1% Perkadox 16)min. 20Hours
Cured Properties
ValueUnitsTest Method / Conditions
Barcol Hardness* (GYZJ 934-1)45
Water Absorption (24h, at 23°C)16mg
Heat Deflection Temperature (under load 1.8 MPa)100°C
Specific Gravity (at 20°C)1.16
Elongation (at break)2.5%
Tensile Strength65MPa
Tensile Modulus3700MPa
Flexural Strength130MPa
Flexural Modulus3700MPa
Notes

Test according to Iso 75A, ISO EN 178 & EN 527
1MPa = 1MN/m2 = 1N/mm2 = 10,2 kgf/cm2
* cured 24 h at 20°C then 3 h à 80°C except for the HDT where the schedule was 24 h at 20°C then 5 h at 80°C then 3h at 100°C.

Regulatory & Compliance

Quality Standards
Approvals

CRYSTIC 4044T V01 is type 1140 according to the German standard DIN 16946 Teil 2 and group 3 according to DIN 18820 Teil 1.

Technical Details & Test Data

Reactivity

The ambient temperature, the quantity and the type of catalyst will control the reactivity of the resin. The time to pic of CRYSTIC 4044T V01 with 0.8% Perkadox 16 and 1% Trigonox C at 80°C is 7 to 8 minutes.

Additives

Since certain pigments, fillers or extra styrene may the affect properties of CRYSTIC 4044T V01 their effect should be evaluated before addition to the formulation.

Safety & Health

Points of Caution

Monomer and solvent vapor concentrations above certain levels can be hazardous to health and safety. The safety risks are associated essentially with the fire and possible explosions. The risks to health come mainly from the build up of vapors in the workplace in excess of certain limits and the limits applicable to the user’s country should be determined. The symptoms of the more common vapors are similar, i.e. dry irritating throat, coughing, drowsiness, headaches. Both liquids and vapors may cause skin irritation and dermatitis to susceptible personnel

Health and Safety Information

The most important protective measures to be taken with unsaturated resins and resin systems are:

  • Correct storage
  • Stock rotation
  • Adequate workplace ventilatio
  • Local extraction where vapor
  • Concentrations may build up or are high
  • Use of fresh air masks in confined spaces or spray applications outside of spray booths
  • Work place monitoring of vapor concentrations
  • Good housekeeping
  • Systematic work routines
  • Competent personnel
  • Supervision, training and instruction
  • Fire precautions
  • Correct disposals

Packaging & Availability

Packaging Type
Packaging
Crystic® 4044T V01 is supplied in 225 kg or 1100 kg containers. Bulk supplies can be delivered by road tanker.

Storage & Handling

Storage
Crystic® 4044T V01 should be stored under cover in the dark in the container in which it is supplied. Storage temperatures should not exceed 20°C. Moreover, Crystic® 4044T V01 should be periodically stirred to avoid sedimentation during the storage period
