ASAHIKLIN™ AE3100E

AGC Chemicals Americas, Inc. ASAHIKLIN™ AE3100E is a fluorinated solvent used for cleaning, alcohol drying, and dewatering. This environmentally sensible, Hydrofluoroether (HFE-347pc-f) is a non-flammable solvent that has excellent material compatibility, low surface tension, low Global Warming Potential (LGWP), and zero Ozone Depletion Potential (ODP).

Brand: ASAHIKLIN (9 products)

Chemical Name: 1,1,2,2-tetrafluoroethyl-2,2,2-trifluoroethyl ether

Functions: Carrier, Drying Agent, Solvent

CAS Number: 406-78-0

Labeling Claims: Corrosive Chloride Quats-free, Environmentally Friendly, Non-Corrosive, Non-Flammable, Recyclable

Technical Data Sheet

Enhanced TDS

Knowde-enriched technical product data sheet

Identification & Functionality

Carrier
Chemical Family
Chemical Name
Base Chemicals Functions
Cleaning Ingredients Functions
CAS No.
406-78-0
EC No.
609-858-6
Technologies
Product Families
Material Composition

1,1,2,2-tetrafluoroethyl-2,2,2-trifluoroethyl ether

92-97

%

Ethanol

3-8%

Features & Benefits

Benefit Claims
Labeling Claims
Base Chemicals Features
HII Features
Benefits
  • Non-flammable
  • Non-corrosive
  • Low global warming potential (GWP)
  • Zero ozone depletion potential (ODP)
  • Excellent thermal, chemical, and hydrolytic stability
  • Low surface tension, low viscosity, high liquid density
  • Superior drying property
  • Excellent permeability
  • Recyclable
  • Recoverable by simple distillation
  • Can be used with ultrasonics
  • No surfactants necessary

Applications & Uses

Markets
Applications
Applicable Processes
Base Chemicals End Uses
Home Care Applications
I&I Cleaning Applications
Plastics & Elastomers End Uses
Applications
  • Defluxing of electronics, electrical components, and printed wiring assemblies
  • Precision cleaning of metals, alloys, composites, and plastics
  • Drying agent after cleaning with hydrocarbons or alcohols
  • Drying after wet plating and for Carbide Metal before coating
  • Particle removal
  • Replacement for HCFC, Dupont™ Vertrel®, & 3M™ Novec™ solvents
Cleaning Procedures

It is recommended that Asahiklin AE3100E be used in a vapor degreaser to optimize cleaning efficiency, economy, and emission control. Cleaning procedures for Asahiklin AE3100E are quite similar to those of AK225 products. The procedures consist of immersing a workload into the boiling solvent, rinsing, or spraying with cool solvent and drying in solvent vapor.

Properties

Physical Form
Physical Properties
ValueUnitsTest Method / Conditions
Boiling Point54 (129.2)ºC(ºF)-
Density (at 25ºC)1.4g/cm³-
Flash PointNone-Open/Closed Cup
Latent Heat of Vaporization (at 51ºC)187KJ/kg-
Melting Point-86 (-122.8)ºC(ºF)-
Relative Evaporation Rate (Ether=100)66--
Specific Heat (at 25ºC)1.49kJ/kg K-
Surface Tension (at 25ºC)16.1dyne/cm-
Vapor Pressure (at 25ºC)0.28kg/cm²-
Viscosity (at 25ºC)0.43cSt-
Material Compatibility

Asahiklin AE3100E has a broad range of compatibilities

Effect of Asahiklin AE3100E on Unstressed Plastics and Elastomers at Boiling Point.



At boiling for 3 days

Weight change (%)

Linear Swell (%)

Polypropylene

<2.5

<2.0

Polystyrene

<2.0

<1

Polymethyl methacrylate

affected

affected

ABS

<7.5

<2.5

PTFE

<2.5

<2.5

Fluoroelastomer

>69

>21

Silicon Rubber

<20

<5.0

EPDM

<0.1

<0.1

Environmental Properties

Properties

Asahiklin AE3100E

Ozone Depletion Potential (ODP)1

None

Global Warming Potential (GWP)2

*580

Flash Point

None

1 CFC-11 = 1.0

2 CO2 = 1.0, 100yr ITH

* Calculated value by the AIST

Packaging & Availability

Packaging Type
