Enhanced TDS
Knowde-enriched technical product data sheet
Identification & Functionality
- Chemical Family
- Polymer Name
- Composite Materials Functions
- Technologies
- Product Families
Features & Benefits
- Materials Features
- Chemical resistance
Crystic VE 676T has excellent chemical resistance to a wide range of substances (acids, alkalis, oxidizing agents) at room and elevated temperatures.
- Features and Benefits
Crystic VE676T is thixotropic version of Crystic VE676, an epoxy bisphenol A based vinyl ester resin.
Applications & Uses
- Markets
- Applications
- Composites End Use
- Composites Processing Methods
- Applications
CRYSTIC VE676T is suitable for hand lay– up, spray lay-up and similar process.
Properties
- Typical Liquid Resin Properties
Value Units Test Method / Conditions Acid Value max. 8 mg KOH/g - Volatile Content 46 - 50 % - Viscosity (at 25°C, Brookfield RVT, sp2, 5 rpm) 1200 - 1800 mPa.s - Viscosity (at 25°C, Brookfield RVT, sp2, 50 rpm) 400 - 600 mPa.s - Index Thix 2.5 - 3.5 - - Gel Time (at 25°C, using 100g resin 1g Cobalt toate (3%) 2g Butanox LPT) 20 - 30 Minutes - Stability (with storage recommendations) 6 Months - - Cured Base Resin
Value Units Test Method / Conditions Barcol Hardness ** 45 - - Tensile Strength** 80 MPa - Tensile Modulus** 3.4 GPa - Elongation (at break)** 4 - 5 % - Heat Deflection Temperature*** 95 - 100 °C - Water Absorption (7 days)** 35 mg - - Note
** Curing Schedule: 24 hrs at 20°C followed by 3hrs at 80°C
*** Curing Schedule: 24 hrs at 20°C followed by 5 hrs at 80°C and then 3hrs at 120°C
Technical Details & Test Data
- Post Curing
Satisfactory laminates for many applications can be made from Crystic VE676T by curing at ambient temperature (20°C). For optimum properties laminates should be post cured before being put into service. The laminate should be allowed to cure for 24 hours at 20°C and then be oven cured for a minimum of 3 hours at 80°C; the time will be dependent upon the thickness of the laminate. Post curing at 100°C is advisable for high operating temperatures.
Packaging & Availability
- Packaging Type
- Packaging
- Crystic® VE676T is supplied in 200 kg drums, 1000 kg containers or in bulk by road tanker.
Storage & Handling
- Storage
- Crystic® VE676T should be stored between 5°C and 25°C in the original, unopened container in a dry, well ventilated place. Protect from freezing and direct sunlight. Avoid contact with oxidizing agents. If stored outside of these recommendations, shelf life will be significantly reduced
