Fluon® PTFE CD123E

Identification & Functionality

Additives Included

Thermal Stabilizer

Chemical Family

Fluoropolymers

Polymer Name

Polytetrafluoroethylene (PTFE)

Plastics & Elastomers Functions

Resin

Technologies

Plastics

Product Families

Plastics — Engineering & Specialty Polymers

High Performance Thermoplastics

Features & Benefits

Materials Features

Free Flowing,

Good Thermal Stability,

High Molecular Weight,

High Tensile Strength

Applications & Uses

Markets

Adhesives & Sealants,

Agriculture & Feed,

Building & Construction,

Printing & Packaging

Applications

Agriculture & Feed — Agricultural Films

Pipes & Hoses

Building & Construction — Building Materials

Pipes & Plumbing

Adhesives & Sealants — Packaging & Paper

Tape & Label Adhesives

Printing & Packaging — Tapes, Labels & Adhesives

Tapes & Labels

Plastics & Elastomers End Uses

Tape,

Tubing

Plastics & Elastomers Processing Methods

Calendering,

Extrusion

End Uses

Fluon CD123E and CD127E are high extrusion pressure polymers which have been designed for paste extrusion at low to medium reduction ratio into tubes including pipe liners. Their excellent stability makes them ideally suited to the long sintering cycles needed when making thick section tubes for pipe liners.

CD123E has higher extrusion pressure and may be used at reduction ratios from 15 to 300:1. CD127E may be used at higher reduction ratios than CD123E. CD123E is also suited to the manufacture of electrical tapes of good tensile strength and good thermal stability.

Properties

Physical Form

Powder,

Solid

Typical Properties

	Value	Units	Test Method / Conditions
Bulk Density	545	kg / m³	FTM 126
Extrusion Pressure (at Reduction Ratio 400:1, 1.59 mm Die)	45	Mpa	FTM 19a
Mean Particle Size	475	microns	FTM 125
Moisture (Weight loss)	max. 0.05	%	FTM 140
Moisture Content (Desiccant Pack Weight Increase 3 Days After Packing)	max. 6	g	FTM 121
Reduction Ratio Range	15 - 300	—	—
SSG	2.16	—	FTM 128

Electrical Tape Production

The following conditions can be used to make normal density tapes from CD123E by extruding a rod or tape and then calendering.

Lubrication/Preforming

Machine	20 te Havelock
Polymer	CD123
Lubricant	18% odorless kerosene
Conditioning time/temperature	24 hr/25ºC
Preform pressure	350 psi



Extrusion

	Rod	Tape
Extrusion cylinder	1.625 in	1.625 in
Die diameter	0.24 in	(0.35) in
Die angle	20º	-
Die temp	30ºC	25ºC
Reduction ratio	46:1	22:1
Ram speed	30 mm/min	30 mm/min
Extrusion pressure	2.8 MPa	6.0 MPa (CD123)



Calendering

	Rod	Tape
Storage of extrudate (kerosene in container)	25ºC	25ºC
Calender bowl diameter	10 in	10 in
Calender bowl temperature	30ºC	30ºC
Calendering speed	10 rpm	8 rpm
Tape thickness	0.006 in (0.15 mm)	0.006 in (0.15 mm)



Drying

	Rod	Tape
Temperature	110ºC	110ºC
Pressure	Vacuum	Vacuum

Tapes made under these conditions have a tensile strength of 7-9 MPa and elongation to break of 200%.



Tubing

The following conditions can be used to make tubing from CD123E on a vertical ram extruder with in-line drying and sintering  followed by air quenching.

	24 mm Tube	42 mm Tube
Machine	150 te Havelock	150 te Havelock
Lubricant (VM&P Naphtha)	17%	17%
Conditioning time/temperature	24 hr/25ºC	24 hr/25ºC
Preform pressure	500 lb/in2	500 lb/in2
Extrusion cylinder	4.5 in	4.5 in
Mandrel diameter	0.75 in	1.5 in
Die diameter	0.9415 in	1.74 in
Die angle	30º	60 º
Core pin diameter	0.74 in	1.65 in
Reduction ratio	60:1	60:1
Extrusion rate (tube speed )	0.15 m/min	0.5m/min
Extrusion pressure	8 MPa	17 MPa
Drying oven temperature	120ºC	120ºC
Drying oven length	3.2 meters	3.2 meters
Residence time	21 min	6.4 min
Sintering oven temperature	450ºC	450ºC
Sintering oven length	1.5 meters	1.5 meters
Residence time	10 min	3 min

Tubes made under these conditions have a smooth surface finish and are white in color.



Regulatory & Compliance

Disposal

Waste polymer should be disposed of by landfill in accordance with any local regulations for the disposal of products of low toxicity or may be incinerated under approved controlled conditions.

Food Contact Approval

Information on food contact approval is available from AGC Chemicals Europe, Ltd sales office.

Technical Details & Test Data

Processing

Fluon CD123E and CD127E can be processed by paste extrusion of a lubricated mix followed by drying and sintering. Further information on these techniques may be found in Technical Service Note F3/4/5, "The processing of Fluon PTFE coagulated dispersion powders".

This information sheet contains typical property data which should not be used for specification purposes.

Packaging & Availability

Packaging Type

Drums

Packaging

Fluon CD123E and CD127E are packed in plastic kegs with plastic lids containing 25 kg.

Storage & Handling

Storage and Handling

Fluon CD123E should be stored in clean dry conditions at 15ºC - 18ºC to ensure they do not become compacted and remain easy to sieve.

The lubricated mixes of powder should be stored at 25ºC for 24 hours before use in air tight containers to ensure that the lubricant is evenly distributed and that the powder will preform and extrude uniformly.
