Knowde Enhanced TDS
Identification & Functionality
- Chemical Family
- Chemical Name
- CASE Ingredients Functions
- Cosmetic Ingredients Functions
- Plastics & Elastomers Functions
- CAS No.
- 7631-86-9
- EC No.
- 231-545-4
- Product Families
Features & Benefits
- Benefit Claims
- Industrial Additives Features
Applications & Uses
- Applications
- Applicable Processes
- Application Format
- Compatible Substrates & Surfaces
- Plastics & Elastomers End Uses
- Use Level
- 1-5%
- Application Information
Cosmetics and Personal Care
SOLESPHERE™ silica gels are used as additives in cosmetic and personal care applications such as make-up, skin care products, deodorants and fragrances.
Resins and Polymer Compounds
When added to polymer formulations, SOLESPHERE™ silica gels offer anti blocking and improved dielectric insulation properties. SOLESPHERE™ also provides good UV and hardness properties as an additive for 3D resins.
Catalyst Supports
SOLESPHERE™ is used as a catalyst support carrier particularly with polyolefin manufacturing processes.
Paper Coating
By adding SOLESPHERE™ to paper coating formulations, surface hardness can be increased and matting effect improved.
Coatings
SOLESPHERE™ silica gels are used to improve the matting effect in coatings, as a thickener for paints, and for specialized paints for electronic materials.
- Formulating with SOLESPHERE™ Silica
SOLESPHERE™ provides excellent formulation flexibility as it can be added to any phase of the formulation. Through product and application testing, it has been shown SOLESPHERE™ silica provides the same effects in the formulation regardless of whether they are added to the water phase/aqueous phase, oil phase, or even if added at the very end.
- The effects of the silicas will show with just 1% added, however, adding more can increase benefits. 2-2.5% is the typical loading level.
- It is not recommended to add more than 3-4% in total silica content. This can result in the formulation appearing “chunky.”
- Multiple SOLESPHERE products can be added to a formulation to achieve different desired goals, but it is important to not go over the 3-4% total.
- Significant SPF boosting with H-53 and H-52 will show with just 1-2% added.
Properties
- Typical Properties
| Value | Units | Test Method / Conditions | |
| Bulk Density | 0.18 | g/mL | — |
| Mean Particle Size | 3 | μm | — |
| Oil Absorption | 150 | mL/100g | — |
| Pore Diameter | 5 | nm | — |
| Pore Volume | 1 | mL/g | — |
| Specific Gravity | 2.16 | g/mL | — |
| Specific Surface Area | 800 | m²/g | — |
Technical Details & Test Data
- Haze and Total Transmittance of SOLESPHERE Grades
The higher the particle size, higher the blur effect and the amount of oil absorption.
- SOLESPHERE™ Particle Structure
- Spherical and non cohesive
- High oil absorption capacity unlike any other
- Applied as new functional material filler
Safety & Health
- Safety and Handling
A Safety Data Sheet for this product may be obtained from your local AGC representative. Before handling, it is recommended to review the Safety Data Sheet for handling, safe, and health information.
Packaging & Availability
- Packaging
SOLESPHERE™ is packaged in a triple lined polyethylene bag contain in a cardboard carton. The box unit is 20 kgs for SOLESPHERE™ H-31. There are 18 boxes per pallet.
Storage & Handling
- Shelf Life
- 2 Years
- Storage and Shelf Life
SOLESPHERE™ silica gels have a shelf life of 2 years from the date of manufacture when stored in the original, unopened package between 10 and 40 ºC.
