LUMIFLON® LF-200F

1 of 31 products in this brand

AGC Chemicals Americas, Inc. LUMIFLON® LF-200F is a moderate molecular weight, moderate hydroxyl number resin consisting of alternating fluoroethylene and alkyl vinyl ether segments (FEVE). This product has been developed in flake form in order to enable formulators to meet VOC and HAPS regulations. This resin can be dissolved in VOC and HAPS exempt solvents such as acetone, Oxsol® 100, t-butyl acetate, and dimethyl carbonate to meet the strictest air quality requirements. LUMIFLON resins are used to make ultra-weatherable coatings for architectural, aerospace, automotive, and industrial maintenance markets.

Chemical Family: Fluoroethylene Vinyl Ether (FEVE)

Compatible Substrates & Surfaces: Aluminum, Metal, Plastics, Steel

Glass Transition Temperature (Tg): 35.0 - 35.0 °C

Features: Chemical Resistance, Good Compatibility, UV Stability, Weather Resistance

Technical Data Sheet

Popular AGC Chemicals Americas, Inc. Products

View All AGC Chemicals Americas, Inc. Products

Knowde Enhanced TDS

Identification & Functionality

Chemical Family: Fluoroethylene Vinyl Ether (FEVE)
CASE Ingredients Functions: Binder & Resin
Technologies: CASE Ingredients
Product Families: CASE Ingredients — Resins & Binders
Other Resins & Binders

Features & Benefits

CASE Ingredients Features: Chemical Resistance,
Good Compatibility,
UV Stability,
Weather Resistance

Properties

Physical Form: Flakes,
Solid
Appearance: Pale yellow flake
Typical Properties
Solubility Data for LUMIFLON LF-200F (ASTM D4287): The viscosity of LUMIFLON LF-200F and LF-916F in a range of solvents was determined. The viscosity results should be compared to those of the resins in xylene, which is the standard solvent for LUMIFLON resins. By the appropriate choice of solvents, coatings
that meet even the most stringent air quality regulations can be formulated with LF-200F

Solvent Solids, Wt. % Brookfield Viscosity, cps

Xylene 49.5 630

61.9 6,284

70.6 >20,000

t-Butyl Acetate 50.2 869

75.2 29,256

Oxsol 100 48.6 6,632

55.6 25,000

Acetone 50.0 250

60.0 975

Dimethyl Carbonate 50.0 825

Methyl Ethyl Ketone (MEK) 50.8 263

68.1 4,714

Methyl Amyl Ketone (MAK) 50.5 470

66.9 6,876

Methyl Acetate 51.8 333

61.6 1,645

66.3 4,186

n-Butyl Acetate 49.9 496

59.2 2,397

PM Acetate 50.9 1573

64.2 20,747

Ethyl 3-Ethoxy Propionate (EEP) 50.7 1,941

64.0 16,729

	Value	Units	Test Method / Conditions
Density (at 25ºC)	1.42	g/cc	—
Glass Transition Temperature	35	°C	—
Hydroxyl Number ( Resin)	45	mg KOH/g	—
Non-Volatiles	min. 98	wt. %	—

Solvent	Solids, Wt. %	Brookfield Viscosity, cps
Xylene	49.5	630
	61.9	6,284
	70.6	>20,000
t-Butyl Acetate	50.2	869
t-Butyl Acetate	75.2	29,256
Oxsol 100	48.6	6,632
Oxsol 100	55.6	25,000
Acetone	50.0	250
Acetone	60.0	975
Dimethyl Carbonate	50.0	825
Methyl Ethyl Ketone (MEK)	50.8	263
Methyl Ethyl Ketone (MEK)	68.1	4,714
Methyl Amyl Ketone (MAK)	50.5	470
Methyl Amyl Ketone (MAK)	66.9	6,876
Methyl Acetate	51.8	333
	61.6	1,645
	66.3	4,186
n-Butyl Acetate	49.9	496
n-Butyl Acetate	59.2	2,397
PM Acetate	50.9	1573
PM Acetate	64.2	20,747
Ethyl 3-Ethoxy Propionate (EEP)	50.7	1,941
Ethyl 3-Ethoxy Propionate (EEP)	64.0	16,729
