AGC Chemicals Americas, Inc. LUMIFLON® LF-916F is a low molecular weight resin that is used to create coatings with high crosslink density. This resin is made of alternating fluoroethylene and alkyl vinyl ether segments (FEVE) and comes in flake form to comply with regulations for VOC and HAPS. It can be dissolved in solvents that are exempt from these regulations, such as acetone, Oxsol® 100, t-butyl acetate, and dimethyl carbonate. These resins are used to produce coatings that are highly resistant to weathering, and are commonly used in various industries like architecture, aerospace, automotive and industrial maintenance.

Chemical Family: Fluoroethylene Vinyl Ether (FEVE)

Compatible Substrates & Surfaces: Aluminum, Metal, Plastics, Steel

Glass Transition Temperature (Tg): 34.0 - 34.0 °C

Features: Chemical Resistance, Good Compatibility, UV Stability, Weather Resistance

Technical Data Sheet

Knowde Enhanced TDS

Identification & Functionality

CASE Ingredients Functions

Features & Benefits

Applications & Uses

Compatible Substrates & Surfaces


Physical Form
Pale yellow flake
Typical Properties
ValueUnitsTest Method / Conditions
Density (at 25ºC)1.39g/cc-
Glass Transition Temperature34°C-
Hydroxyl Number ( Resin)100mg KOH/g-
Non-Volatiles99wt. %-
Solubility Data for LUMIFLON LF-916F (ASTM D4287)

The viscosity of LUMIFLON LF-200F and LF-916F in a range of solvents was determined. The viscosity results should be compared to those of the resins in xylene, which is the standard solvent for LUMIFLON resins. By the appropriate choice of solvents, coatings that meet even the most stringent air quality regulations can be formulated with LF-916F.

Solvent Solids, Wt. % Brookfield Viscosity, cps
Xylene 50.1 202
64.8 1,709
- -
t-Butyl Acetate 42.9 869
64.3 2,074
Oxsol 100 50.5 1,748
61.2 12,425
Acetone 50.0 22
65.0 240
Dimethyl Carbonate 60.0 375
Methyl Ethyl Ketone (MEK) 52.0 44
70.6 922
Methyl Amyl Ketone (MAK) 63.3 579
71.9 3,808
Methyl Acetate 59.9 157
66.7 565
70.6 1,200
n-Butyl Acetate 49.9 96
62.5 613
PM Acetate 49.5 192
61.1 1,151
Ethyl 3-Ethoxy Propionate (EEP) 48.6 160
70.8 11,000
