Knowde Enhanced TDS
Identification & Functionality
- Chemical Family
- Polymer Name
- Technologies
- Product Families
Features & Benefits
- Materials Features
- Specific Features
- Low viscosity
- Reduced volatile content
Applications & Uses
- Plastics & Elastomers End Uses
- Plastics & Elastomers Processing Methods
- Applications
Cable Accessories
- Application Details
The material fits very well all requirements for manufacturing of large articles with special dosing and metering equipment because of it`s low viscosity.
- Insulators and cable accessories
- Manufacturing of large articles
- Injection molding or special dosing equipment
Processing
The A and B components are delivered ready to use in 20 kg pail and 200 kg drum kits. With adequate metering equipment, they can be pumped directly from the original containers into the injection molding machine and mixed by a static mixer. The mixing ratio is 1 : 1.
Properties
- Cured Properties
- Uncured Properties
- Properties
- Very easy to process due to its low viscosity
- Excellent dielectrical properties
- Good mechanical properties
- Note
Cure conditions: 5 min / 165°C in press, post-cured 4 h / 200°C.
| Value | Units | Test Method / Conditions | |
| Compression Set (at 22 hours, 175°C) | 11 | % | DIN ISO 815-1 type B method A |
| Density | 1.09 | g/cm³ | DIN EN ISO 1183-1 A |
| Dielectric Strength (1mm sheet) | 23 | kV/mm | IEC 60243-1 |
| Dissipation Factor (tan δ, at 50Hz) | 50 x 10⁻⁴ | — | IEC 62631-2-1 |
| Elongation (at break) | 460 | % | ISO 37 Type 1 |
| Permittivity (at 50Hz) | 3 | — | IEC 62631-2-1 |
| Shore Hardness A | 33 | — | DIN ISO 48-4 |
| Tear Strength | 25 | N/mm | ASTM D 624 B |
| Tensile Strength | 7 | N/mm² | ISO 37 Type 1 |
| Volume Resistivity | 10¹⁵ | Ohm-cm | IEC 62631-3-1 |
| Value | Units | Test Method / Conditions | |
| Dynamic Viscosity (Shear rate 1 s⁻¹) | 130000 | mPa·s | DIN EN ISO 3219 |
| Dynamic Viscosity (Shear rate 10 s⁻¹) | 55000 | mPa·s | DIN EN ISO 3219 |
Regulatory & Compliance
- Certifications & Compliance
Packaging & Availability
- Country Availability
- Regional Availability
- Packaging Information
This product is available in 20 kg pail and 200 kg drum kits.
Storage & Handling
- Storage Information
Once opened, containers should always be resealed after use to prevent the platinum catalyst from being poisoned by amines, sulfur or phosphorus compounds.
