Knowde Enhanced TDS
Identification & Functionality
- Chemical Family
- Polymer Name
- Technologies
- Product Families
Features & Benefits
- Materials Features
- Ready-to-Use Product Features
- Special Features
- Addition Curing
- Electrically conductive
- Two-component
Applications & Uses
- Markets
- Cure Method
- Plastics & Elastomers End Uses
- Applications
- Ignition & Battery Cables
- Molded Parts
- Profiles & Tubings
- Application Details
Electrically conductive profiles, EMI-gaskets, ignition cables (core), band electrodes.
Processing
- ELASTOSIL® R 573/50 A/B is delivered as A- & B-component system.
- ELASTOSIL® R 573/50 A/B are homogeneously mixed in a ration of 1 : 1. Care must be taken to keep the compound cool during mixing. Crosslinking begins when mixing both components together. The rate and degree of crosslinking depends on the storage time and temperature.
- At 23 °C the mixture has a pot life of about 24 h. This can be extended by storing the catalyzed mixture at a lower temperature.
- A homogeneous mixture is a must, but please avoid temperatures >30 °C along the mixing process in order to maintain best processing behavior.
Properties
- Cured Properties
- Properties
This product is an addition cured electrically conductive HCR silicone rubber which shows a low volume resistivity.
- Note
Cure conditions: 15 min / 165 °C in press, post-cured 30 min / 200 °C.
| Value | Units | Test Method / Conditions | |
| Compression Set (at 22 hours, 175°C) | 30 | % | DIN ISO 815-1 type B method A |
| Density | 1.11 | g/cm³ | DIN EN ISO 1183-1 A |
| Elongation (at break) | 340 | % | ISO 37 Type 1 |
| Rebound Resilience | 58 | % | ISO 4662 |
| Shore Hardness A | 50 | — | DIN ISO 48-4 |
| Tear Strength | 13 | N/mm | ASTM D 624 B |
| Tensile Strength | 5.5 | N/mm² | ISO 37 Type 1 |
| Volume Resistivity | 7 | Ohm-cm | IEC 62631-3-1 |
Regulatory & Compliance
- Certifications & Compliance
Packaging & Availability
- Country Availability
- Regional Availability
- Packaging Information
This product is available in 20 kg and 540 kg cardboard packaging.
Storage & Handling
- Storage Information
Please store the cardboard boxes in a dry and cool place. Already opened boxes should be closed again to avoid any contamination.
