Knowde Enhanced TDS
Identification & Functionality
- Additives Included
- Chemical Family
- Polymer Name
- Technologies
- Product Families
Features & Benefits
- Materials Features
- Special Features
- Addition Curing
- Two-component
Applications & Uses
- Markets
- Applications
- Cure Method
- Plastics & Elastomers End Uses
- Plastics & Elastomers Processing Methods
- Applications
- E-Mobility Cables for EV/HEV
- Ignition & Battery Cables
- Application Details
Processing
- The raw rubber requires the addition of a platinum catalyst for vulcanization at elevated temperatures. A homogeneous incorporation is a must, but please avoid temperatures >30°C along the incorporation process in order to maintain best processing behavior.
- Pot life is depending on the used catalyst and storage condition. ELASTOSIL® R plus 5305/70 and ELASTOSIL® AUX PT 1 are homogeneously mixed in a ratio of 100 : 1.5.
- Care must be taken to keep the compound cool during mixing. Crosslinking begins when ELASTOSIL® AUX PT 1 has been added. The rate and degree of crosslinking depend on the storage time and temperature. At 23 °C the mixture has a pot life of about 24 h. This can be extended by storing the catalyzed mixture at a lower temperature.
Properties
- Typical Properties
- Cured Properties
- Properties
This product can be used within a temperature range of - 55 °C to + 210 °C. The addition of heat stabilizers at service temperatures of more than 180 °C is recommended.
- Note
Cure conditions: 15 min / 165 °C in press, post-cured 4 h / 200 °C for cured properties.
Value | Units | Test Method / Conditions | |
Pot Life (at 23°C) | 24 | Hours | — |
Value | Units | Test Method / Conditions | |
Compression Set (at 22 hours, 175°C) | 10 | % | DIN ISO 815-1 type B method A |
Density | 1.18 | g/cm³ | DIN EN ISO 1183-1 A |
Elongation (at break) | 590 | % | ISO 37 Type 1 |
Rebound Resilience | 57 | % | ISO 4662 |
Shore Hardness A | 70 | — | DIN ISO 48-4 |
Tear Strength | 42 | N/mm | ASTM D 624 B |
Tensile Strength | 9.2 | N/mm² | ISO 37 Type 1 |
Regulatory & Compliance
- Certifications & Compliance
Packaging & Availability
- Country Availability
- Regional Availability
- Packaging Information
This product is available in 20 kg and 540 kg cardboard packaging.
Storage & Handling
- Storage Information
Please store the cardboard boxes in a dry and cool place. Once opened, cardboard boxes should always be resealed after use to prevent the platinum catalyst from being poisoned by amines, sulfur or phosphorus compounds.
