Knowde Enhanced TDS
Identification & Functionality
- Chemical Family
- Polymer Name
- Technologies
- Product Families
Features & Benefits
- Labeling Claims
- Materials Features
- Special Features
- Flexible at low (-40 °C) and high temperatures (+180 °C)
- Low viscosity
Applications & Uses
- Applications
- Cure Method
- Plastics & Elastomers End Uses
- Applications
Oil & Gas
- Application Details
ELASTOSIL® SUB C 2000 A/B is the silicone rubber of choice to manufacture all types of thermal insulating devices Main field of application: Thermal insulation material for marine applications, e.g. deep-sea constructions and subsea oil production equipment.
Processing
Surface preparation:
All surfaces must be clean and free of contaminants that will inhibit the cure of ELASTOSIL® Sub C 2000 A/B. Examples of inhibiting contaminants are sulfur containing materials, plasticizers, urethanes, amine containing materials and organometallic compounds – especially organotin compounds. If a substrate’s ability to inhibit cure is unknown, a small scale test should be run to determine compatibility.
Mixing:
- Only A and B components with the same batch number may be processed together.
- Component A of ELASTOSIL® Sub C 2000 A/B contains the platinum catalyst, component B the crosslinker. Even traces of the platinum catalyst may cause gelling of the component containing the crosslinker. Therefore tools (spatula, stirrers, etc.) used for handling the platinum-containing component or the catalyzed compound must not come into contact with this component.
- The two components should be thoroughly mixed at a 10 : 1 ratio by weight or volume. To eliminate any air eventually introduced during mixing, the A/B mix can be deaerated under vacuum prior use (25-50 mbar, 10-15 min). For processing ELASTOSIL® Sub C 2000 A/B in industrial scale, the use of automatic mixing and dispensing equipment is recommended.
Curing:
- The curing time of addition-curing silicone rubber is highly dependent on temperature, size and heat sink properties of the components being potted or bonded. The reactivity can be adjusted within wide limits by adding Catalyst EP or Inhibitor PT 88 to suit the processing requirements of the particular application.
- Catalyst EP increases the reactivity, i.e. pot life and curing time are reduced. Inhibitor PT 88 is a pot life extender and prolongs pot life and curing time.
- After completion of the vulcanization process the product may be exposed continuously and without damage to marine or subsea conditions, UV radiation, temperature levels as high as 150 °C (302 °F) and isostatic water pressure of up to 200 bar.
Cleaning:
If removal of silicone rubber from machines or dispensing equipment is necessary, white spirit or similar non-polar solvents are recommended. However, cleaning ideally should take place before the rubber is fully vulcanized. Cured silicone rubber can be removed by mechanical means, preferably in combination with a swelling agent (solvent).
Properties
- Color
- Catalyst Properties
- Cured Properties
- Uncured Properties
- Properties
- Two-part system, 10:1 mixing ratio
- Fast and non-shrink curing at room temperature
- Translucent, pigmentable in any color
- Excellent durability under subsea conditions
- Note
Cured properties are cured in press: 165°C / 10 min.
| Value | Units | Test Method / Conditions | |
| Dynamic Viscosity (A+B, at 25°C, Shear rate 0.5 s⁻¹) | 30000 | mPa·s | DIN EN ISO 3219 |
| Mix Ratio (A:B) | 10:1 | parts by weight | — |
| Pot Life (A+B, at 25°C) | 90 | minutes | ISO 6721-10 |
| Value | Units | Test Method / Conditions | |
| Demoldable | min. 12 | hours | — |
| Density (at 23°C) | 1.07 | g/cm³ | DIN EN ISO 1183-1 A |
| Elongation (at break, 23°C, t=2mm) | 300 | % | ISO 37 Type 1 |
| Linear Shrinkage | max. 0.1 | % | — |
| Shore Hardness A | 44 | — | DIN ISO 48-4 |
| Tear Strength (at 23°C, t = 2 mm) | 25 | N/mm | ASTM D 624 B |
| Tensile Strength (at 23°C, t=2mm) | 4.5 | N/mm² | ISO 37 Type 1 |
| Thermal Conductivity | max. 0.2 | W/m.K | DIN 52612 |
| Value | Units | Test Method / Conditions | |
| Density (at 23°C, Componenet A) | 1.08 | g/cm³ | DIN EN ISO 2811-1 |
| Density (at 23°C, Componenet B) | 0.97 | g/cm³ | DIN EN ISO 2811-1 |
| Dynamic Viscosity (Component A, at 25°C, Shear rate 0.5 s⁻¹) | 55000 | mPa·s | DIN EN ISO 3219 |
| Dynamic Viscosity (Component A, at 25°C, Shear rate 25 s⁻¹) | 40000 | mPa·s | DIN EN ISO 3219 |
| Dynamic Viscosity (Component B, at 25°C) | 400 | mPa·s | ISO 3219 |
Regulatory & Compliance
- Certifications & Compliance
Packaging & Availability
- Country Availability
- Regional Availability
Storage & Handling
- Storage Information
ELASTOSIL® SUB C 2000 A/B should be stored dry and cool in the tightly closed original container.
