Knowde Enhanced TDS
Identification & Functionality
- Carrier
- Chemical Family
- Technologies
- Product Families
Features & Benefits
- Labeling Claims
- Materials Features
- Ready-to-Use Product Features
- Special Features
- Coolant resistant
- Heat resistant
- Low viscosity
- Oil resistant
- One-component
- Solvent-free
Applications & Uses
- Applications
- Application Area
- Application Method
- Cure Method
- Applications
- Cured-In-Place-Gaskets (Dry Type)
- Fiber Gaskets
- Screen Printing
- Transportation
- Application Details
- ELASTOSIL N 294 is particularly suited for screen-printing. It can be applied and cured on diverse substrates. It works both on sulfur containing or sulfur free substrates. Typical use is screen printing on fiber based cylinder head gaskets.
- If a top coating is needed, condensation cure materials have to be used to avoid contact inhibition effects. Some filler may settle during transport and storage. To ensure a uniform mix, the components should be thoroughly stirred prior to use.
- ELASTOSIL® N294 is a moisture curing silicone sealant. For this reason the curing rate strongly depends on both temperature and atmospheric humidity in the surrounding.ELASTOSIL® N294 can be applied with standard silkscreen printing equipment.
Processing
Some filler may settle during transport and storage. To ensure a uniform mix, the components should be thoroughly stirred prior to use. ELASTOSIL® N 294 is a moisture curing silicone sealant. For this reason the curing rate strongly depends on both temperature and atmospheric humidity in the surrounding (see table below). ELASTOSIL® N 294 can be applied with standard silkscreen printing equipment.
Temperature with steam Curing time, thickness 0.1 mm in a circulating air oven
150 °C 30 min 175 °C 15 min 200 °C 10 min 175 °C 5 min
Properties
- Cured Properties
- Uncured Properties
- Properties
- Resistant to high temperatures
- Resistant to mineraloil and coolant
- Solvent free
- Long open time
- Note
Curing conditions: 2 mm, 14 days storage at 23°C and 50% RH.
| Value | Units | Test Method / Conditions | |
| Density (in water, at 23°C) | 1.21 | g/cm³ | DIN EN ISO 1183-1 A |
| Elongation (at break, Type 3, 23°C, 2mm) | 300 | % | ISO 37 |
| Shore Hardness A | 33 | — | DIN ISO 48-4 |
| Tear Resistance (at 23°C, 2mm) | 4.5 | N/mm | ASTM D 624 B |
| Tensile Strength (Type 3, at 23°C, 2mm) | 2.2 | N/mm² | ISO 37 |
| Value | Units | Test Method / Conditions | |
| Density | 1.2 | g/cm³ | DIN EN ISO 2811-1 |
| Dynamic Viscosity (at 25°C, after stirring, Spindle 4, 2.5 Upm) | 22000 | mPa·s | DIN EN ISO 2555 |
| Skin Formating Time (at 23°C, 50% r.h) | 6 | hours | — |
Regulatory & Compliance
- Certifications & Compliance
Packaging & Availability
- Country Availability
- Regional Availability
- Availability
Available in red and blue
