Knowde Enhanced TDS
Identification & Functionality
- Chemical Family
- Polymer Name
- Technologies
- Product Families
Features & Benefits
- Labeling Claims
- Materials Features
- Specific Features
- Excellent hydrophobicity behavior
- High LOI
- Resistant to tracking and erosion
Applications & Uses
- Markets
- Applications
- Cure Method
- Plastics & Elastomers End Uses
- Plastics & Elastomers Processing Methods
- Applications
- Arresters
- Insulators
- Application Details
POWERSIL® 310 MH is the silicone rubber of choice for the manufacture all types of electrical insulating equipment for outdoor use, e.g. composite insulators, arrester housings, bushings etc.
Processing
POWERSIL® 310 MH can be processed using injection molding, transfer or compression molding. For detailed information please refer to our brochure "Solid and Liquid Silicone Rubber, Material and Processing Guidlines". To achieve a good bond between typically-used materials for electrical insulation equipment and POWERSIL® 310 MH the primer G 3243 should be used.
Properties
- Cured Properties
- Properties
- Very good arc resistance
- Suitable dielectric properties
- Good mechanical properties
- Note
Cure conditions: 15 min / 165°C in press.
| Value | Units | Test Method / Conditions | |
| Arc Resistance | min. 300 | seconds | IEC 61621 |
| Density | 1.55 | g/cm³ | DIN EN ISO 1183-1 A |
| Dielectric Strength | 23 | kV/mm | IEC 60243-1 |
| Dissipation Factor (tan δ, at 50Hz) | 2x10⁻² | — | IEC 62631-2-1 |
| Elongation (at break) | 200 | % | ISO 37 Type 1 |
| Permittivity (at 50Hz) | 3.7 | — | IEC 62631-2-1 |
| Shore Hardness A | 70 | — | DIN ISO 48-4 |
| Tear Strength | 11 | N/mm | ASTM D 624 B |
| Tensile Strength | 5 | N/mm² | ISO 37 Type 1 |
| Tracking Resistance | 1A 4.5 | — | IEC 60587 |
| Volume Resistivity | 1x10¹⁴ | Ohm-cm | IEC 62631-3-1 |
Regulatory & Compliance
- Certifications & Compliance
- Chemical Inventories
- Quality Standards
Packaging & Availability
- Country Availability
- Regional Availability
- Packaging Information
This product is available in 20 kg and 540 kg cardboard packaging. Special delivery forms are possible but depend on several technical and commercial aspects.
Storage & Handling
- Storage Information
The containers must be protected against sunlight. Keep separate from organic rubber and crosslinker chemicals.
