Knowde Enhanced TDS
Identification & Functionality
- Chemical Family
- Product Type
- Technologies
Features & Benefits
- Ready-to-Use Product Features
Applications & Uses
- Markets
- Applications
- Application Area
- Cure Method
- Applications
- Electronic Control Unit (ECU)
- Power Control Unit (PCU)
- Application Details
- CIPG applications for plastic and metal housings
- FIPG applications for plastic and metal housings
- Dam material for dam-and-fill applications
- Sealing and gasketing of housings
Processing
Surface Preparation
All surfaces must be clean and free of contaminants that will inhibit the cure of SEMICOSIL® 9882. Examples of inhibiting contaminants are sulfur containing materials, plasticizers, urethanes, amine containing materials and organometallic compounds – especially organotin compounds. If a substrate’s ability to inhibit cure is unknown, a small scale test should be run to determine compatibility.
Mixing
Component A of SEMICOSIL® 9882 contains the platinum catalyst, component B the crosslinker. Even traces of the platinum catalyst may cause curing of the component containing the crosslinker. Therefore tools (spatula, stirrers, etc.) used for handling the platinum-containing component or the catalyzed compound must not come into contact with this component. The two components should be thoroughly mixed at a 1:1 ratio by weight. To eliminate any air introduced during mixing or trapped under components or devices a vacuum de-airing under a vacuum of 10 – 20 mm mercury for 5 – 10 min is recommended.
Curing
Curing time of addition-curing silicone rubber is highly dependent on temperature, silicone amount, size and heat sink properties of the substrate the silicone is applied on. We recommend running preliminary tests to optimize conditions for the particular application. SEMICOSIL® 9882 shows good primerless adhesion to many substrates. We recommend running preliminary tests to optimize conditions for the particular application.
Properties
- Typical Properties
- Catalyst Properties
- Cured Properties
- Uncured Properties
- Properties
- Thixotropic, pasty
- Low hardness, low modulus
- Excellent compression set properties
- Excellent elongation
- Fast curing at 80°C
- Primerless adhesion on many substrates
- UV-tracer
- Note
Cured properties are press cured at 165°C for 5 min.
| Value | Units | Test Method / Conditions | |
| Pot Life (at 23°C) | 60 | Minutes | — |
| Value | Units | Test Method / Conditions | |
| Curing Time (thickness: 3mm, at 100°C) | 10 | minutes | — |
| Curing Time (thickness: 3mm, at 60°C) | 30 | minutes | — |
| Dynamic Viscosity (at 25°C, Shear rate 0.5 s⁻¹) | 450000 | mPa·s | ISO 3219 |
| Dynamic Viscosity (at 25°C, Shear rate 25 s⁻¹) | 55000 | mPa·s | ISO 3219 |
| Mix Ratio (A:B) | 1:1 | parts by weight | — |
| Platinum Catalyst in Component | Component A | — | — |
| Pot Life (at 23°C) | 1 | hours | DIN EN ISO 3219 |
| Value | Units | Test Method / Conditions | |
| Curing Time (3 mm, at 100°C) | 10 | Minutes | — |
| Curing Time (3 mm, at 60°C) | 30 | Minutes | — |
| Compression Set (at 22 hours, 125°C) | max. 30 | % | DIN ISO 815-1 type B method A |
| Density (at 23°C) | 1.1 | g/cm³ | DIN EN ISO 1183-1 A |
| Elongation (at break, 23°C, t=2mm) | 400 | % | ISO 37 Type 1 |
| Lap Shear Strength (on pickled aluminum, at 23°C, 0.2mm) | min. 2 | N/mm² | DIN EN 1465 |
| Modulus (at 100 % elongation, 23°C) | 0.5 | N/mm² | ISO 37 Type 1 |
| Shore Hardness A | 32 | — | DIN ISO 48-4 |
| Tensile Strength | 5 | N/mm² | ISO 37 Type 1 |
| Value | Units | Test Method / Conditions | |
| Density (at 23°C, Componenet A) | 1.1 | g/cm³ | DIN EN ISO 1183-1 |
| Density (at 23°C, Componenet B) | 1.1 | g/cm³ | DIN EN ISO 1183-1 |
| Dynamic Viscosity (Component A, at 25°C, Shear rate 0.5 s⁻¹) | 350000 | mPa·s | ISO 3219 |
| Dynamic Viscosity (Component A, at 25°C, Shear rate 25 s⁻¹) | 57000 | mPa·s | ISO 3219 |
| Dynamic Viscosity (Component B, at 25°C, Shear rate 0.5 s⁻¹) | 520000 | mPa·s | ISO 3219 |
| Dynamic Viscosity (Component B, at 25°C, Shear rate 25 s⁻¹) | 60000 | mPa·s | ISO 3219 |
Regulatory & Compliance
- Certifications & Compliance
Packaging & Availability
- Country Availability
- Regional Availability
