ELASTOSIL® LR 3005/30 A/B

ELASTOSIL® LR 3005/30 A/B is a liquid silicone rubber of the ELASTOSIL® LR 3005 series. It is a paste-like, easily pigmentable, two-component compound with short curing times. The vulcanizates of this product are renowned for their high transparency as well as their exceptional mechanical and electrical properties. Due to the excellent compression set, there is no need to post-cure technical parts.

Brand: ELASTOSIL® LR (114 products)

Polymer Name: Liquid Silicone Rubber (LSR)

Processing Methods: Injection Molding

End Uses: Automobile Door Seals, Batteries, Vibration Dampers

Features: Cost Effective, Fast Curing, Good Electrical Properties, Good Mechanical Properties, Heat Stabilized, Low Compression Set, Low VOC, Low Volatility, Pigmentable

Tear Strength: 16.0 - 16.0 kN/m

Technical Data Sheet

Enhanced TDS

Knowde-enriched technical product data sheet

Identification & Functionality

Features & Benefits

Materials Features
Specific Features
  • Food-contact
  • Low compression set without post-cure
  • Reduced volatile content

Applications & Uses

Markets
Applications
Plastics & Elastomers End Uses
Plastics & Elastomers Processing Methods
Applications

  • Battery
  •
  • Connector Seals
  •
  • General Automotive Parts
  •
  • Molded Parts
  •
  • Molded Seals (LSR)
  •
  • Vibration Dampers
  •
Application Details

These grades are particularly suitable for the economical production of large series of injection-molded articles. Parts made from ELASTOSIL® LR 3005 are particularly suitable for the economical production of large series of injection molded articles. They can generally be used for technical applications without post-curing, but do not comply with regulations in the pharmaceutical and food industry.

Processing

  • The A and B components are delivered ready to use in 20 kg pail and 200 kg drum kits. With adequate metering equipment, they can be pumped directly from the original containers into the injection molding machine and mixed by a static mixer.
  • The mixing ratio is 1 : 1. At room temperature, mixtures of A and B components have a pot life of at least one day.
  • The vulcanization (t90 value) is 20 to 50% shorter than of products in the ELASTOSIL® LR 3003 series.
  • This consequently leads to a decrease in cycle times and thus to cost savings, depending on the injection-molded articles.

Properties

Physical Form
Cured Properties
ValueUnitsTest Method / Conditions
Compression Set (at 22 hours, 175°C)13%DIN ISO 815-1 type B method A
Density1.1g/cm³DIN EN ISO 1183-1 A
Dielectric Strength (1mm sheet)25kV/mmIEC 60243-1
Dissipation Factor (tan δ, at 50Hz)11 x 10⁻⁴ -IEC 62631-2-1
Elongation (at break)610%ISO 37 Type 1
Permittivity (at 50Hz)2.8-IEC 62631-2-1
Rebound Resilience65%ISO 4662
Shore Hardness A30-DIN ISO 48-4
Tear Strength16N/mmASTM D 624 B
Tensile Strength6N/mm²ISO 37 Type 1
Volume Resistivity1 x 10¹⁶ Ohm-cmIEC 62631-3-1
Uncured Properties
ValueUnitsTest Method / Conditions
Dynamic Viscosity (Shear rate 1 s⁻¹)270000mPa·sDIN EN ISO 3219
Dynamic Viscosity (Shear rate 10 s⁻¹)130000mPa·sDIN EN ISO 3219
Properties

Narrow Shore hardness range from 28 to 34 Shore A (31 ± 3 Shore A). This product can be used within a temperature range of - 55°C to + 210°C. The addition of heat stabilizers at service temperatures of more than 180°C is recommended.

Note

Cure conditions : 5 min / 165°C in press.

Regulatory & Compliance

Packaging & Availability

Country Availability
Packaging Type
Regional Availability
  • Africa
  • Asia
  • Europe
  • Latin America
  • Middle East
  • North America
  • Oceania
Packaging Information

This product is available in 20 kg pail and 200 kg drum kits.

Storage & Handling

Storage Information

Once opened, containers should always be resealed after use to prevent the platinum catalyst from being poisoned by amines, sulfur or phosphorus compounds.
