Knowde Enhanced TDS
Identification & Functionality
- Chemical Family
- Technologies
- Product Families
Features & Benefits
- Materials Features
Applications & Uses
- Applications
- Application Area
- Cure Method
- Applications
- Automotive Electronics
- Battery
- Electrics & Electronics
- Power Control Unit (PCU)
- Power Electronics
- Thermal Interface Management
- Application Details
Interface material for heat sink applications for the electronics industry
Processing
The platinum catalyst is contained in component A. Only components A and B with the same lot number may be processed together.
Temperature Curing time, thickness 6mm, 90% cure
25°C 300 min 100°C 5 min
Properties
- Flame Rating
- Physical Form
- Catalyst Properties
- Technical Data
- Cured Properties
- Uncured Properties
- Properties
- Gap filler, thermal conductivity 2.3 W/mK
- Two-part, RT curing
- Constant properties from –50 °C to 130 °C
- Low stress, soft and tacky
- D4-D8 < 350 ppm
- Note
Cured for 5 min at 165°C
| Value | Units | Test Method / Conditions | |
| Dynamic Viscosity (A+B, Catalyzed, at 23°C, Shear rate 10 s⁻¹) | 130000 | mPa·s | ISO 3219 |
| Mix Ratio (A:B) | 1:1 | parts by weight | — |
| Platinum Catalyst in Component (A+B) | Component A | — | — |
| Pot Life (A+B, at 23°C, up to 300,000 mPa.s) | 60 | minutes | DIN EN ISO 3219 |
| Value | Units | Test Method / Conditions | |
| Thermal Conductivity | 2.3 | W/mK | — |
| Value | Units | Test Method / Conditions | |
| Density (in water, at 23°C) | 2.9 | g/cm³ | DIN EN ISO 1183-1 A |
| Dielectric Strength | 8 | kV/mm | IEC 60243-1 |
| Flame Rating | V-0 | — | Internal test acc. UL94 |
| Heat Capacity | 1 | J/gK | — |
| Shore Hardness 00 | 55 | — | ASTM D 2240 |
| Siloxane D4-D8 | max. 350 ppm | ppm | NSCG012 |
| Thermal Conductivity | 2.3 | W/m.K | ASTM D 5470-12 |
| Volume Resistivity | min. 10¹³ | Ohm-cm | IEC 62631-3-1 |
| Value | Units | Test Method / Conditions | |
| Density (at 23°C, Componenet A) | 2.9 | g/cm³ | DIN EN ISO 1183-1 A |
| Dynamic Viscosity (Component A, at 23°C, Shear rate 10 s⁻¹) | 130000 | mPa·s | ISO 3219 |
| Dynamic Viscosity (Component B, at 23°C, Shear rate 10 s⁻¹) | 130000 | mPa·s | ISO 3219 |
Regulatory & Compliance
- Certifications & Compliance
Packaging & Availability
- Country Availability
- Regional Availability
